Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
33
HEADPHONE LCDCONTROL LOADING MAIN
< VARIABLE RESISTOR >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
RV802 1-418-859-11 ENCODER, ROTARY (TREBLE)
RV803 1-418-859-11 ENCODER, ROTARY (BASS)
< SWITCH >
S801 1-571-760-11 SWITCH, KEY BOARD (TUNING MODE)
S802 1-571-760-11 SWITCH, KEY BOARD (CD u)
S803 1-571-760-11 SWITCH, KEY BOARD (CD x)
S804 1-571-760-11 SWITCH, KEY BOARD (CD >)
S805 1-571-760-11 SWITCH, KEY BOARD (CD .)
S806 1-571-760-11 SWITCH, KEY BOARD (CD PLAY MODE)
S807 1-571-760-11 SWITCH, KEY BOARD (CD REPEAT)
S808 1-571-760-11 SWITCH, KEY BOARD (CD Z)
S809 1-571-760-11 SWITCH, KEY BOARD (TAPE Y)
S810 1-571-760-11 SWITCH, KEY BOARD (TAPE x)
S811 1-571-760-11 SWITCH, KEY BOARD (TAPE >)
S812 1-571-760-11 SWITCH, KEY BOARD (TAPE .)
S813 1-571-760-11 SWITCH, KEY BOARD (TAPE X)
S814 1-571-760-11 SWITCH, KEY BOARD (TAPE REC)
S815 1-571-760-11 SWITCH, KEY BOARD (TUNING +)
S816 1-571-760-11 SWITCH, KEY BOARD (TUNING -)
S817 1-571-760-11 SWITCH, KEY BOARD (STANDBY)
S818 1-571-760-11 SWITCH, KEY BOARD (CD)
S819 1-571-760-11 SWITCH, KEY BOARD (TUNER)
S820 1-571-760-11 SWITCH, KEY BOARD (TAPE)
S821 1-571-760-11 SWITCH, KEY BOARD (MD/VIDEO)
S822 1-571-760-11 SWITCH, KEY BOARD (DSG)
S823 1-571-760-11 SWITCH, KEY BOARD (TUNER BAND)
S824 1-571-760-11 SWITCH, KEY BOARD (CD SYNC)
S825 1-571-760-11 SWITCH, KEY BOARD (SELECT)
S826 1-571-760-11 SWITCH, KEY BOARD (PREV)
S827 1-571-760-11 SWITCH, KEY BOARD (NEXT)
S828 1-571-760-11 SWITCH, KEY BOARD (RETURN)
************************************************************
1-677-147-21 HEADPHONE BOARD
****************
< CAPACITOR >
C132 1-124-584-00 ELECT 100uF 20% 10V
C134 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C232 1-124-584-00 ELECT 100uF 20% 10V
C234 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
< JACK >
J301 1-785-925-11 JACK (PHONES)
J402 1-793-570-11 JACK (MIC IN)
< TRANSISTOR >
Q132 8-729-920-31 TRANSISTOR DTC343TK
Q232 8-729-920-31 TRANSISTOR DTC343TK
< RESISTOR >
R128 1-216-019-00 METAL CHIP 56 5% 1/10W
R228 1-216-019-00 METAL CHIP 56 5% 1/10W
< VARIABLE RESISTOR >
RV200 1-225-916-11 RES, VAR, CARBON 20K (MIC VOL)
************************************************************
1-678-282-11 LCD BOARD
*********
1-792-412-11 CABLE, FLEXIBLE FLAT (20 CORE)
1-792-413-11 CABLE, FLEXIBLE FLAT (18 CORE)
< CONNECTOR >
CN801 1-785-950-11 CONNECTOR, FFC/FPC 18P
CN803 1-785-949-11 CONNECTOR, FFC/FPC 20P
< DIODE >
D657 8-719-075-51 DIODE SELS6B14C-LF62 (LCD BACK LIGHT)
D658 8-719-075-51 DIODE SELS6B14C-LF62 (LCD BACK LIGHT)
D659 8-719-075-51 DIODE SELS6B14C-LF62 (LCD BACK LIGHT)
D660 8-719-075-51 DIODE SELS6B14C-LF62 (LCD BACK LIGHT)
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R647 1-249-407-11 CARBON 150 5% 1/4W F
(TH)
R647 1-249-408-11 CARBON 180 5% 1/4W F
(SP,MY,EA,HK)
R649 1-249-407-11 CARBON 150 5% 1/4W F
(TH)
R649 1-249-408-11 CARBON 180 5% 1/4W F
(SP,MY,EA,HK)
************************************************************
1-676-599-11 LOADING BOARD
**************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE)
************************************************************
A-4475-100-A MAIN BOARD, COMPLETE (TH)
*********************
A-4428-930-A MAIN BOARD, COMPLETE (SP,MY,HK)
*********************
A-4475-103-A MAIN BOARD, COMPLETE (EA)
*********************
4-230-078-01 SCREW, +BV TAPPING (SP,MY,HK)
* 4-217-354-01 BUSHING, INSULATING
7-685-535-19 SCREW +BTP 2.6X10 TYPE2 N-S
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20.00% 50V
C102 1-126-963-11 ELECT 4.7uF 20.00% 50V
C103 1-126-963-11 ELECT 4.7uF 20.00% 50V
C104 1-126-963-11 ELECT 4.7uF 20.00% 50V
C105 1-126-963-11 ELECT 4.7uF 20.00% 50V
