SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• CAPACITORS:
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
• Abbreviation
SP : Singapore model.
MY : Malaysia model.
HK : Hong Kong model.
TH : Thai model.
EA : Saudi Arabia model.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
CONTROL
A-4428-925-A CONTROL BOARD, COMPLETE
************************
1-792-410-11 CABLE, FLEXIBLE FLAT (23 CORE)
< CAPACITOR >
C601 1-124-259-11 ELECT 4.7uF 20.00% 16V
C602 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
< CONNECTOR >
CN805 1-794-393-11 CONNECTOR, FFC/FPC 23P
< DIODE >
D500 8-719-074-40 DIODE SLR325DU-T31 (VCD ON)
D501 8-719-074-40 DIODE SLR325DU-T31 (PBC)
D851 8-719-074-42 DIODE SLR325VR-T31 (STANDBY)
D852 8-719-074-40 DIODE SLR325DU-T31 (CD)
D853 8-719-074-40 DIODE SLR325DU-T31 (MD/VIDEO)
D854 8-719-074-40 DIODE SLR325DU-T31 (TAPE)
D855 8-719-074-40 DIODE SLR325DU-T31 (TUNER)
D856 8-719-074-42 DIODE SLR325VR-T31 (DSG)
D857 8-719-074-42 DIODE SLR325VR-T31 (CD SYNC)
D858 8-719-075-50 DIODE SELS6B14C-TP5 (CD DISC)
< IC >
IC802 8-742-132-00 HYB SBX1976-51P (REMOTE CONTROL
RECEIVER)
< TRANSISTOR >
Q500 8-729-900-53 TRANSISTOR DTC114EK
Q501 8-729-900-53 TRANSISTOR DTC114EK
Q852 8-729-900-53 TRANSISTOR DTC114EK
Q853 8-729-900-53 TRANSISTOR DTC114EK
Q854 8-729-900-53 TRANSISTOR DTC114EK
Q855 8-729-900-53 TRANSISTOR DTC114EK
Q856 8-729-900-53 TRANSISTOR DTC114EK
Q857 8-729-900-53 TRANSISTOR DTC114EK
Q858 8-729-900-53 TRANSISTOR DTC114EK
Q859 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R500 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R501 1-216-045-00 METAL CHIP 680 5% 1/10W
R502 1-216-047-91 RES-CHIP 820 5% 1/10W
R503 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R504 1-216-043-91 RES-CHIP 560 5% 1/10W
R505 1-216-043-91 RES-CHIP 560 5% 1/10W
R590 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R591 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R592 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R593 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R601 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R602 1-216-045-00 METAL CHIP 680 5% 1/10W
R603 1-216-047-91 RES-CHIP 820 5% 1/10W
R604 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R605 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R606 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R607 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R608 1-216-079-00 METAL CHIP 18K 5% 1/10W
R609 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R610 1-216-045-00 METAL CHIP 680 5% 1/10W
R611 1-216-047-91 RES-CHIP 820 5% 1/10W
R612 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R614 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R615 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R616 1-216-079-00 METAL CHIP 18K 5% 1/10W
R617 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R618 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R660 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R661 1-216-033-00 METAL CHIP 220 5% 1/10W
R662 1-216-043-91 RES-CHIP 560 5% 1/10W
R666 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R667 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R668 1-216-041-00 METAL CHIP 470 5% 1/10W
R669 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R680 1-216-045-00 METAL CHIP 680 5% 1/10W
R681 1-216-047-91 RES-CHIP 820 5% 1/10W
R683 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R684 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R685 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R686 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R687 1-216-079-00 METAL CHIP 18K 5% 1/10W
R688 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
