3-3. FRONT PANEL SECTION
1 Connector
(CN303)
3 Connector
2 Flat wire
Two claws
6 Screw
(KTP3
× 6)
7 Front panel section
(There is a claw.)
5 Two screws
(BTP3
× 8)
4 Screw
(TP3
× 6)
