40
<LENS2>
M07
REMOTE CONTROL ON, OFF
, (OFF) Lens remote control from MSU/RCP on/off setting.
Same function as the Active button on the Zoom/
Focus Control screen of the MSU/RCP.
(OFF): When lens is not supported
CONTROL MODE ZOOM & FOCUS
, FOCUS,
FOLLOW FOCUS
ZOOM & FOCUS: Control ZOOM and FOCUS from an
MSU/RCP (control by lens demand is not
supported)
FOCUS: Control FOCUS from an MSU/RCP. ZOOM is
controlled by lens demand.
FOLLOW FOCUS: FOCUS is controlled by lens
demand, but can be adjusted (offset fine
adjustment) from an MSU/RCP. ZOOM is controlled
by lens demand.
Note
Settings other than FOLLOW FOCUS cannot be
modified when the offset is not 0 and REMOTE
CONTROL is OFF. To change settings, set REMOTE
CONTROL to ON.
FOLLOW FOCUS
OFFSET ADJUST
SENS
1, 2, 3
, 4, 5 Sets the sensitivity of superimposing the offset of the
MSU.
OFFSET CANCEL
GAIN
1, 2, 3
, 4, 5 Sets the sensitivity of canceling the offset on the
demand side.
<MIC GAIN>
M08
MIC 20, 30, 40, 50, 60
dB Enabled in standalone mode.
+48V ON, OFF
MUTE ON, OFF
<CALL/TALLY>
M09
CCU CALL OFF, ON
CAM CALL OFF, ON
FRONT TALLY OFF, ON
BRIGHTNESS 0 to 100, 50
REAR TALLY OFF, ON
<SYSTEM FORMAT>
M10 (U09)
CURRENT 1080/50P (2×), 50P (3×), 50P
(4×), 50P (6×), 50P (8×), 59.94P
(2×), 59.94P (3×), 59.94P (4×),
59.94P (6×), 59.94P (8×)
720/50P (2×), 50P (3×), 50P (4×),
50P (6×), 50P (8×), 59.94P (2×),
59.94P (3×), 59.94P (4×), 59.94P
(6×), 59.94P (8×)
4096×2160/23.98P, 24P, 25P,
29.97P, 50P, 59.94P, 50P (2×),
59.94P (2×)
Displays the current format.
When a BPU is connected.
1080/59.94P, 29.97PsF,
23.98PsF, 50P, 25PsF, 24PsF
In standalone mode.
CHANGE 1080/59.94P, 29.97PsF,
23.98PsF, 50P, 25PsF, 24PsF
Displayed only in standalone operation.
Changes the format.
<SDI OUT>
M11 (U10)
SDI-1 OUT VF,
MAIN(i), RET, HD
PROMPTER
EMB AUDIO OFF
, MIC, PGM
SDI-2 OUT/IN 3G-SDI OUT, MAIN(i) OUT
, RET
OUT, HD PROMPTER OUT,
HD-TRUNK IN
MAINTENANCE
Page name
Page No.
Item Settings Description
