41
FILE Menu
Five types of files can be used for easy adjustments of the
camera; Operator, Reference, Scene, OHB, and Lens.
You can store the items set with the OPERATION menu and
customized USER menu in the Operator file.
For the specific items included in these files, refer to the
Maintenance Manual.
<TRUNK>
M12
TRUNK ON, OFF
INTERFACE 232c
, 422A
NETWORK TRUNK Display only
LINK
<GENLOCK>
M13
REFERENCE Synchronization status Display only
<DATE>
M14
DATE/TIME 2000 to 2099/01 to 12/00 to 31
00 to 23 : 00 to 59
DATE FORMAT 1 Y/Mn/D, 2 Mn/D, 3 D/M/Y,
4 D/M, 5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (English abbreviation)
D: Day
<BATTERY ALARM>
M15
BEFORE END 11.5
to 17.0 V
END 11.0
to 11.5 V
BATTERY ALARM OFF, ON
<OTHERS>
M16
FAN MODE OFF, AUTO1, AUTO2, MIN, MAX AUTO1: Normal rotation
AUTO2: Slow rotation
CAM BARS ON, OFF
Enabled in standalone mode.
WHITE SETUP MODE AWB, A.LVL
<OPTION KEY>
M17
READ (USB t CAM) Execute using ENTER. Reads the install key from a USB drive.
EFFECTIVE FUNCTION Displays only installed items.
MAINTENANCE
Page name
Page No.
Item Settings Description
FILE
Page name
Page No.
Item Settings Description
<OPERATOR FILE>
F01
READ (USB t CAM) Execute using ENTER. Reads the operator file from a USB drive.
WRITE (CAM t USB) Execute using ENTER. Writes the current settings of the operator file items to
a USB drive.
PRESET Execute using ENTER. Sets the operator file items to the preset values in
internal memory.
STORE PRESET FILE Execute using ENTER. Stores the current settings of the operator file items in
the operator file in internal memory.
FILE ID Max. 14 characters Enters a comment for the operator file to be written to
a USB drive.
See “To specify a character string” (page 18).
CAM CODE Camera code Display only
DATE Date Display only
To Next Page
