44
DIAGNOSIS Menu
This menu is for viewing only; camera settings cannot be made using this menu.
However, some items set the conditions for viewing.
<FILE CLEAR>
F09
PRESET OPERATOR Execute using ENTER.
REFERENCE (ALL) Execute using ENTER.
10 SEC CLEAR ON, OFF
Sets the function to clear the selected menu item to
ON/OFF.
See “To return a menu item to its standard value”
(page 18).
OHB WHITE SHADE (ALL)
Execute using ENTER.
OHB BLACK SHADE Execute using ENTER.
OHB ND OFFSET Execute using ENTER.
DIAGNOSIS
Page name
Page No.
Item Indication Description
<OPTICAL LEVEL>
D01
CCU t BPU t CAM GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU or BPU is
connected.
CAM t BPU t CCU GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU or BPU is
connected.
CABLE LENGTH x.x km Displays the camera cable length.
(Displayed only when a CCU is connected.)
<BOARD STATUS>
D02
OHB OK, NG
DPR OK, NG
SY OK, NG
PS OK, NG
HOURS METER xxxx H Displays the total working time.
<ROM VERSION>
D03 (U11)
CAMERA APP Vx.xx
OS Vx.xx
SY Vx.xx
DPR Vx.xx
<SERIAL No.>
D04
MODEL HDC-P43
NO. xxxxxxx
EFFECTIVE FUNCTION Displayed if any option is installed.
FILE
Page name
Page No.
Item Settings Description
