1-5
HDC1000/V2 (J, E)
CCD Unit (HDC1000/1100)
No. Part No. SP Description
101
!
A-1099-261-A s MOUNTED CIRCUIT BOARD, CN-2578 (for HDC1000)
!
A-1099-206-A s MOUNTED CIRCUIT BOARD, CN-2712 (for HDC1100)
102 A-1153-996-C s CCD UNIT 1000HDC (for HDC1000)
A-1153-997-B s CCD UNIT 1100HDC (for HDC1100)
103
!
*
A-1159-980-A s MOUNTED CIRCUIT BOARD, TG-243G (GOLD) (for HDC1000)
!
*
A-1101-922-A s MOUNTED CIRCUIT BOARD, TG-243 (SILVER) (for HDC1000)
!
*
A-1159-992-A s MOUNTED CIRCUIT BOARD, TG-247G (GOLD) (for HDC1100)
!
*
A-1126-983-A s MOUNTED CIRCUIT BOARD, TG-247 (SILVER) (for HDC1100)
104
!
*
A-1159-981-A s MOUNTED CIRCUIT BOARD, DR-528G (GOLD) (for HDC1000)
!
*
A-1099-260-A s MOUNTED CIRCUIT BOARD, DR-528 (SILVER) (for HDC1000)
!
*
A-1159-993-A s MOUNTED CIRCUIT BOARD, DR-562G (GOLD) (for HDC1100)
!
*
A-1099-205-A s MOUNTED CIRCUIT BOARD, DR-562 (SILVER) (for HDC1100)
105
!
*
A-1159-982-A s MOUNTED CIRCUIT BOARD, PA-317G (GOLD) (for HDC1000)
!
*
A-1099-263-A s MOUNTED CIRCUIT BOARD, PA-317 (SILVER) (for HDC1000)
!
*
A-1159-994-A s MOUNTED CIRCUIT BOARD, PA-327G (GOLD) (for HDC1100)
!
*
A-1099-203-A s MOUNTED CIRCUIT BOARD, PA-327 (SILVER) (for HDC1100)
106
!
*
A-1159-983-A s MOUNTED CIRCUIT BOARD, CN-2579G (GOLD) (for HDC1000)
!
*
A-1099-262-A s MOUNTED CIRCUIT BOARD, CN-2579 (SILVER) (for HDC1000)
!
*
A-1159-995-A s MOUNTED CIRCUIT BOARD, CN-2723G (GOLD) (for HDC1100)
!
*
A-1099-210-A s MOUNTED CIRCUIT BOARD, CN-2723 (SILVER) (for HDC1100)
107 1-758-483-11 o FILTER UNIT, OPTICAL
108
*
1-831-656-11 s CABLE, FLEXIBLE FLAT (30 CORE) (GOLD)
*
1-830-735-11 s CABLE, FLEXIBLE FLAT (30 CORE) (SILVER)
109
*
1-831-659-11 s CABLE, FLEXIBLE FLAT (45 CORE) (GOLD) (for HDC1000)
*
1-830-484-11 s CABLE, FLEXIBLE FLAT (45 CORE) (SILVER) (for HDC1000)
*
1-831-660-11 s CABLE, FLEXIBLE FLAT (50 CORE) (GOLD) (for HDC1100)
*
1-830-794-11 s CABLE, FLEXIBLE FLAT (50 CORE) (SILVER) (for HDC1100)
110
*
1-831-658-11 s CABLE, FLEXIBLE FLAT (40 CORE) (GOLD)
*
1-830-485-11 s CABLE, FLEXIBLE FLAT (40 CORE) (SILVER)
111 3-699-048-01 s CAP,MOUNT
112 3-729-076-11 s SCREW +B2X4 (STEEL)
113 3-965-077-01 s SCREW, SPECIAL (M2)
114 4-644-165-01 s SCREW (M2.6X4),0 PLATE P1 MAIN
115 3-729-013-31 s HEAD (+P1.4X3),WASHER
116 9-885-001-63 s LEVER, MOUNT
117 9-885-018-96 s RING, BAYONET
7-627-452-18 s SCREW,PRECISION +K 2X3
*
:
*
: Refer to Section 1-6. “Notes for Replacing Parts” of the Maintenance Manual volume 1.
