<HEADSET MIC>
18 (U11)
INTERCOM1 DYNAMIC
, CARBON, MANUAL
LEVEL –60 dB, –50 dB, –40 dB, –30 dB,
–20 dB, (–60 dB
), (–50 dB), (–40
dB), (–30 dB), (–20 dB)
Settings in ( ): With DYNAMIC or CARBON (cannot
be changed)
–6, 0
, 6 dB Input gain
POWER ON, OFF, (ON), (OFF
) Settings in ( ): With DYNAMIC or CARBON (cannot
be changed)
UNBAL ON, OFF, (ON)
, (OFF) Settings in ( ): With CARBON (cannot be changed)
INTERCOM2 DYNAMIC
, CARBON, MANUAL
LEVEL –60 dB, –50 dB, –40 dB, –30 dB,
–20 dB, (–60 dB
), (–50 dB), (–40
dB), (–30 dB), (–20 dB)
Settings in ( ): With DYNAMIC or CARBON (cannot
be changed)
–6, 0
, 6 dB Input gain
POWER ON, OFF, (ON), (OFF
) Settings in ( ): With DYNAMIC or CARBON (cannot
be changed)
UNBAL ON
, OFF, (ON), (OFF) Settings in ( ): With CARBON (cannot be changed)
<INTERCOM1>
19
INTERCOM1
RECEIVE SELECT
SEPARATE
, MIX
INTERCOM --- , LEFT
, RIGHT, BOTH JN/SY models only
When ENG/PROD is set to MIX, ENG and PROD
appears instead of this item (the setting values are
same as this item).
ENG --- , LEFT
, RIGHT, BOTH
PROD --- , LEFT
, RIGHT, BOTH
PGM1 --- , LEFT, RIGHT
, BOTH
PGM2 --- , LEFT, RIGHT
, BOTH
TRACKER --- , LEFT
, RIGHT, BOTH
SIDE TONE MU, 1 to 99, 50
INTERCOM1/2 SEPARATE, MIX
ENG/PROD SEPARATE
, MIX JN/SY models only
<INTERCOM2>
20
INTERCOM2
RECEIVE SELECT
SEPARATE
, MIX
INTERCOM --- , LEFT
, RIGHT, BOTH JN/SY models only
When ENG/PROD is set to MIX, ENG and PROD
appears instead of this item (the setting values are
same as this item).
ENG --- , LEFT
, RIGHT, BOTH
PROD --- , LEFT
, RIGHT, BOTH
PGM1 --- , LEFT, RIGHT
, BOTH
PGM2 --- , LEFT, RIGHT
, BOTH
TRACKER ---
, LEFT, RIGHT, BOTH
SIDE TONE MU, 1 to 99, 50
INTERCOM1/2 SEPARATE, MIX
ENG/PROD SEPARATE
, MIX JN/SY models only
