DIAGNOSIS Menu
This menu is only for viewing and camera settings cannot be
made using this menu.
However, some items set the conditions for viewing.
DIAGNOSIS
Page title
PageNo.
Item Indication Description
<OPTICAL LEVEL>
D01
CCU t CAM GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU is connected.
CAM t CCU GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU is connected.
CABLE LENGTH x.x km Displays the camera cable length.
(Displayed only when a CCU is connected.)
<BOARD STATUS>
D02
OHB OK, NG
DPR OK, NG
SY OK, NG
PS OK, NG
SDI OK, NG
HOURS METER xxxx H Displays the total working time.
<ROM VERSION>
D03 (U15)
CAMERA APP Vx.xx
OS Vx.xx
PANEL Vx.xx Displayed only when HDLA is attached.
HKCT Vx.xx Displayed only when HKC-T1500 is
installed.
TG Vx.xx
SY Vx.xx
DPR1 Vx.xx
DPR2 Vx.xx
DPR3 Vx.xx
SDI Vx.xx
<SERIAL NO.>
D04
MODEL HDC1700
NO. xxxxxxx
EFFECTIVE FUNCTION Displayed if any option is installed.
<POWER SUPPLY
STATUS>
D05
Note
This display has a
margin of error for the
display of the electric
supply state of a
camera. Use only as a
guide.
CAM INPUT VOLTAGE 0% to 100%, 100% OVER Displays the ratio of the input voltage for a
camera to the output voltage for a CCU.
CAM CONSUMPTION xx.x A Displays camera current consumption.
CABLE LENGTH x.x km Displays the cable length that a CCU
measured. (Displayed only when a CCU is
connected.)
