Sony HDC1700 - MAINTENANCE Menu Item Settings

53
MAINTENANCE Menu
MAINTENANCE
Page title
PageNo.
Item Settings Description
<AUTO SETUP>
M01
AUTO BLACK Execute via ENTER.
AUTO WHITE Execute via ENTER.
AUTO LEVEL Execute via ENTER.
AUTO WHITE
SHADING
Execute via ENTER.
AUTO BLACK
SHADING
Execute via ENTER.
TEST OFF
, SAW, 10STEP
<WHITE SHADING>
M02
V SAW R/G/B: –99 to +99, 0
R, G, and B values can be independently set.
V PARA R/G/B: –99 to +99, 0
H SAW R/G/B: –99 to +99, 0
H PARA R/G/B: –99 to +99, 0
WHITE R/G/B: –99 to +99, 0
AUTO WHITE
SHADING
Execute by ENTER.
WHITE SHAD MODE RGB, RB
<BLACK SHADING>
M03
V SAW R/G/B: –99 to +99, 0 R, G, and B values can be independently set.
M (master) value can also be set for BLACK.
V PARA R/G/B: –99 to +99, 0
H SAW R/G/B: –99 to +99, 0
H PARA R/G/B: –99 to +99, 0
BLK SET R/G/B: –99 to +99, 0
BLACK R/G/B/M: –99 to +99, 0
MASTER GAIN –6, –3, 0, 3, 6, 9, 12 dB
AUTO BLACK
SHADING
Execute via ENTER.
2D BLACK SHADING ON
, OFF
<OHB MATRIX>
M04
PHASE 0
, 23, 45, 68, 90, 113, 135, 158,
180, 203, 225, 248, 270, 293, 315,
338
Selects an axis (angle) at PHASE for which the
OHB matrix adjustment is to be made, and set HUE
and SAT. (HUE and SAT can be adjusted
independently for 16 axes.)
HUE –99 to +99, 0
SAT –99 to +99, 0
ALL CLEAR Execute via ENTER. Clears the HUE and SAT values for all PHASE
settings.
OHB MATRIX ON, OFF
MATRIX ON, OFF
