Specifications
Design and specifications are subject to change without
notice.
Optional Accessories/Related
Equipment
General
Power requirements AC 240 V, 1.4 A (max.)
DC 180 V, 1.0 A (max.)
DC 12 V, 7 A (max.)
Operating temperature –20°C to +45°C (–4°F to +113°F)
Storage temperature –20°C to +60°C (–4°F to +140°F)
Mass Approx. 4.5 kg (9 lb 15 oz) (Unit only)
Dimensions See page 65.
Imager
Imager 2/3-type Progressive Scan CCD
Method 3-CCD, RGB
Effective resolution 1920 (horizontal) × 1080 (vertical)
Electrical characteristics
Sensitivity F10.0 with 1080/59.94i
F11.0 with 1080/50i
(at 2000 lx with 89.9% reflectivity)
Image S/N Typical –60 dB
Horizontal resolution 1000 TV lines (at center of screen)
5% or higher modulation
Geometric distortion Negligible (not including lens distortion)
Optical system specifications
Spectral system F1.4 prism
Built-in filters 1: clear
2: 1/4ND
3: 1/16ND
4: 1/64ND
5: cross filter
Input/output connectors
CCU Optical/electrical multi-connector (1)
LENS 12-pin (1)
VF 20-pin (1)
MIC 1 IN XLR 3-pin, female (1)
AUDIO IN CH1, CH2 XLR 3-pin, female (1 each)
AUDIO switch for MIC: –60 dBu (can be
selected up to –20 dBu by menu or
HDCU1700 operations), balanced
AUDIO switch for LINE: 0 dBu, balanced
INTERCOM 1,
INTERCOM 2
XLR 5-pin, female (1 each)
EARPHONE Stereo minijack (1)
DC IN XLR 4-pin (1), DC 10.5 V to 17 V
DC OUT 4-pin (1), DC 10.5 V to 17 V, max. 0.5 A
(This may be limited by the imposed load or
inputs.)
SDI-MONI BNC-type (1)
TEST OUT BNC-type (1)
PROMPTER/
GENLOCK
BNC-type (1), 1 Vp-p, 75 ohms
RET CTRL 6-pin (1)
REMOTE 8-pin (1)
TRACKER 10-pin (1)
CRANE 12-pin (1)
USB USB 2.0 Type A 4-pin (1) (for connecting
USB drive)
Supplied accessories
Operation guide (1)
Operation manual (CD-ROM) (1)
Cable clamp belt (1 set)
Camera number label (1)
Screws (+B3×8) (2)
Optional Accessories
HD Electronic
Viewfinder
HDVF-20A (2-type, monochrome)
HDVF-200 (2-type, monochrome)
HDVF-EL20 (0.7-type, color)
HDVF-EL30 (0.7-type, color)
HDVF-EL75 (7.4-type, color)
HDVF-L750 (7-type, color)
HDVF-L770 (7-type, color)
Large Lens Adaptor HDLA1500/1505
Large Viewfinder
Adaptor
HDLA1507
CCD Block Adaptor HKC-T1500
Microphone Holder CAC-12
Return Video Selector CAC-6
Viewfinder Rotation
Bracket
BKW-401
Dual Optical Filter Unit HKC-DF20
Tripod Attachment VCT-14
Low-repulsion
Shoulder Pad
A-8286-346-A
Camera Operating
Software
HZC-PSF20/PSF20M/PSF20W
HZC-PRV20/PRV20M/PRV20W
HZC-UG444/UG444M/UG444W
Related Equipment
HDCU1700 HD Camera Control Unit
RCP-1000 series Remote Control Panel
MSU-1000 series Master Setup Unit
CNU-700 Camera Command Network Unit
HZC-CSM10 Camera System Management Software
CNA-1 Camera Control Network Adaptor
