56
<SDI OUT>
M12 (U14)
SDI-MONI OUT MAIN, VF
, RET, SD-SDI, OFF
CHARACTER ON, OFF
EMB AUDIO OFF, MIC, PGM
DOWN CONVERTER SDI-MONI OUT is displayed for SD-SDI.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
<TRUNK>
M13
TRUNK ON
, OFF
INTERFACE 232c
, 422A
AUX REMOTE Display only
<GENLOCK>
M14
REFERENCE Condition of synchronisation Display only
GENLOCK ENABLE
, DISABLE Displayed only when no CCU connected.
STATUS
FORMAT
PHASE
V –1024 to 1023, 0
H –1700 to 1700, 0
<DATE>
M15
DATE/TIME 2000 to 2099 / 01 to 12 / 00 to 31,
00 to 23 : 00 to 59
DATE FORMAT 1 Y/Mn/D, 2 Mn/D, 3 D/M/Y, 4 D/M,
5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (character string)
D: Day
<BATTERY ALARM>
M16
BEFORE END 11.5
to 17.0 V
END 11.0
to 11.5 V
<OTHERS>
M17
FAN MODE OFF, AUTO1
, AUTO2 , MIN, MAX AUTO1: Normal rotation
AUTO2: Slow rotation
CAM BARS ON, OFF
WHITE SETUP MODE AWB, A.LVL
STANDALONE SW
DISABLE
OFF, ON When set to ON, disables operation of the unit’s
switches, such as the WHITE BAL switch, even
when a CCU, or control panel is not connected.
<OPTION KEY>
M18
READ (USB t CAM) Execute via ENTER. Reads the install key from a USB drive.
EFFECTIVE
FUNCTION
USER GAMMA, 4:4:4 FORMAT,
PsF FORMAT, 1080P FORMAT
Displayed only when an option has been installed.
<CAM MODE>
M19
Note
When <CAM MODE> is
set to 4K/HDR MODE,
DOWN CONVERTER is
not available.
Only the CHARACTER
information is displayed
when <CAM MODE> is
set to 4K/HDR MODE and
SD-SDI or VBS is
selected.
CURRENT NORMAL, 4K/HDR MODE
(DOWNCONV INVALID)
Displays the current CAM MODE setting.
CHANGE 4K/HDR MODE (DOWNCONV
INVALID), NORMAL
Switches the CAM MODE setting.
MAINTENANCE
Page title
PageNo.
Item Settings Description
