Sony HDR-FX7 - Right Cabinet Section Disassembly

2-6
HDR-FX7/FX7E_L2
2-1-5. CABINET (R) SECTION
Follow the disassembly in the numerical order given.
1 Switch Block Control (CF18500) (1-1 to 1-14)
2 RR-003 Board (2-1 to 2-5)
3 LCD Panel Block (3-1 to 3-4)
EXPLODED VIEW
HARDWARE LIST
3 LCD Panel
Block
1-7 (#53)
2 RR-003 Board
1 Switch Block
Control (CF18500)
2-1
3-2
(Claw)
2-2
2-4
3-1 (#50)
3-3 (#53)
1-14
2-3
1-4
1-9
3-4
1-8 (#53)
1-12 (#53)
1-6 (#1)
1-5 (Open the Jack Cover)
2-5 (#53)
HELP
HELP
R
R
-003
W
W
-
003
1-11
1-13
(Claw)
HELP
1-1
(#53)
1-3
1-10
Note:On installation of the RR-003 Board,
adjust the position of the ZEBRA
switch and the ZEBRA knob.
1-2
(#50)
HELP
