2-9E
HDR-SR1/SR1E_L2
2-1-8. CABINET (L) SECTION-2
EXPLODED VIEW
HARDWARE LIST
Follow the disassembly in the numerical order given.
1 FP-523 Flexible Board (1-1 to 1-11)
2 Switch Block Assy (2-1 to 2-7)
1 FP-523
Flexible Board
1-3
1-4 (#14)
1-1 (#12)
1-6
1-7 (#12)
1-9
1-8
1-10
(#3)
1-11
2 Switch Block
Assy
2-3 (Boss)
2-4 (Boss)
2-5
2-7
2-1 (#12)
2-2
(#14)
2-6 (Boss)
1-2 (#12)
1-5
(#12)
