HDR-SR1/SR1E_L2
Adhesive sheet
5 Put the FP-463 flexible board on
the hinge assy by the adhesive sheet
according to the position of the boss.
4 Roll the FP-463 flexible board 1.5 times,
in the direction of arrow
A.
Boss
1.5 times
A
