5-17
Ref. No. Part No. Description Ref. No. Part No. Description
HDR-SR1/SR1E_L2
A-1173-667-A FP-431 FLEXIBLE BOARD, COMPLETE
******************************
< RESISTOR >
R001 1-218-929-11 RES-CHIP 10 5% 1/16W
R002 1-218-929-11 RES-CHIP 10 5% 1/16W
R003 1-218-929-11 RES-CHIP 10 5% 1/16W
R004 1-218-929-11 RES-CHIP 10 5% 1/16W
R005 1-218-929-11 RES-CHIP 10 5% 1/16W
R006 1-218-929-11 RES-CHIP 10 5% 1/16W
R007 1-218-929-11 RES-CHIP 10 5% 1/16W
R008 1-218-929-11 RES-CHIP 10 5% 1/16W
R009 1-218-929-11 RES-CHIP 10 5% 1/16W
R010 1-218-929-11 RES-CHIP 10 5% 1/16W
R011 1-218-929-11 RES-CHIP 10 5% 1/16W
R012 1-218-929-11 RES-CHIP 10 5% 1/16W
R013 1-218-929-11 RES-CHIP 10 5% 1/16W
R014 1-218-929-11 RES-CHIP 10 5% 1/16W
R015 1-218-929-11 RES-CHIP 10 5% 1/16W
R016 1-218-929-11 RES-CHIP 10 5% 1/16W
A-1201-506-A FP-461 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
CN7001 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
* CN7002 1-817-555-51 CONNECTOR, FFC/FPC 8P
A-1201-509-A FP-469 FLEXIBLE BOARD, COMPLETE
*******************************
< DIODE >
D7201 6-500-252-01 DIODE SML-512WWT86 (FLASH)
< SWITCH >
S7201 1-786-157-31 TACTILE SWITCH (BACK LIGHT)
S7202 1-771-731-21 SWITCH, SLIDE (NIGHTSHOT)
S7203 1-786-157-31 TACTILE SWITCH (FLASH)
S7204 1-786-157-31 TACTILE SWITCH (MANUAL)
A-1201-512-A FP-470 FLEXIBLE BOARD, COMPLETE
*******************************
< JACK >
J7301 1-691-737-41 JACK (SMALL TYPE) (MIC (PLUG IN POWER))
A-1201-513-A FP-471 FLEXIBLE BOARD, COMPLETE
*******************************
< BATTERY TERMINAL >
0 BT7401 1-694-990-11 BATTERY TERMINAL BOARD
< JACK >
0 J7401 1-817-361-11 DC-IN CONNECTOR (DC IN)
A-1201-514-A FP-473 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
* CN7601 1-819-696-21 CONNECTOR, HDMI (HDMI OUT)
A-1201-510-A FP-475 FLEXIBLE BOARD, COMPLETE
*******************************
< SWITCH >
S7801 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
* 1-869-618-11 FP-477 FLEXIBLE BOARD
*********************
(C001 is not included in the FP-477 flexible board.)
< CAPACITOR >
0* C001 1-112-939-11 CAP, ELECT 86uF 330V
A-1201-511-A FP-478 FLEXIBLE BOARD, COMPLETE
*******************************
< IC >
IC7901 6-705-011-01 IC AN48830B-NL
A-1214-519-A FP-523 FLEXIBLE BOARD, COMPLETE
*******************************
< FERRITE BEAD >
FB8101 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB8102 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB8103 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
< JACK >
J8101 1-793-995-21 JACK, SUPER SMALL TYPE (REMOTE)
J8102 1-569-950-41 JACK (SMALL TYPE) (i (HEADPHONE))
< RESISTOR >
R8101 1-216-864-11 SHORT CHIP 0
R8102 1-216-864-11 SHORT CHIP 0
R8103 1-216-864-11 SHORT CHIP 0
R8104 1-216-864-11 SHORT CHIP 0
< VARISTOR >
VD8101 1-801-862-11 VARISTOR, CHIP (1608)
VD8102 1-801-862-11 VARISTOR, CHIP (1608)
A-1201-502-A FR-256 BOARD, COMPLETE
**********************
< CAPACITOR >
C5901 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C5902 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
FP-431 FP-461 FP-469 FP-470 FP-471 FP-473 FP-475 FP-477
• Refer to page 5-1 for mark 0.
FP-478 FP-523 FR-256
