5-18
Ref. No. Part No. Description Ref. No. Part No. Description
HDR-SR1/SR1E_L2
< CONNECTOR >
CN5901 1-818-043-51 CONNECTOR, FFC/FPC 10P
< DIODE >
D5901 8-719-073-01 DIODE MA111-(K8).S0
D5902 8-719-064-07 DIODE SML-310LTT86
(CAMERA RECORDING)
D5903 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT)
< IC >
IC5901 6-600-163-01 IC RS-770
< RESISTOR >
R5901 1-218-937-11 RES-CHIP 47 5% 1/16W
R5902 1-218-951-11 RES-CHIP 680 5% 1/16W
A-1201-490-A JK-313 BOARD, COMPLETE
**********************
< CONNECTOR >
CN8001 1-818-607-12 CONNECTOR, SQUARE TYPE 10P
(COMPONENT OUT)
CN8002 1-815-794-13 CONNECTOR (MULTIPLE) (A/V OUT)
* CN8003 1-819-780-51 CONNECTOR, FPC (ZIF) 27P
< DIODE >
D8001 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D8002 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D8003 6-500-750-01 DIODE NSAD500H-T1-A
D8004 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D8005 6-500-044-01 DIODE DF6A6.8FU (TE85R)
< FERRITE BEAD >
FB8001 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB8002 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
< RESISTOR >
R8001 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8002 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8003 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8004 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8005 1-218-990-81 SHORT CHIP 0
R8006 1-218-990-81 SHORT CHIP 0
R8007 1-218-990-81 SHORT CHIP 0
R8008 1-400-833-21 SMD EMI FERRITE (Note)
R8009 1-400-833-21 SMD EMI FERRITE (Note)
R8010 1-400-833-21 SMD EMI FERRITE (Note)
R8011 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8012 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
R8013 1-469-581-21 INDUCTOR, FERRITE BEAD (1005) (Note)
Note: Ferrite beads are mounted to the location where
R8001, R8002, R8003, R8004, R8008, R8009,
R8010, R8011, R8012 and R8013 are printed.
Note: R8001，R8002，R8003，R8004，R8008，
R8009，R8010，R8011，R8012，R8013にはフェ
ライトビーズがマウントされています。
FR-256 JK-313
Electrical parts list of the LD-226 and MD-
133 boards are not shown.
Pages 5-19 to 5-23 are not shown.
