5-24
Ref. No. Part No. Description Ref. No. Part No. Description
HDR-SR1/SR1E_L2
A-1201-504-A MS-328 BOARD, COMPLETE
***********************
< CAPACITOR >
C7503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN7501 1-817-827-11 MEMORY STICK DUO CONNECTOR
CN7502 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P)
CN7503 1-779-335-51 CONNECTOR, FFC/FPC 22P
< DIODE >
D7501 6-501-638-01 DIODE CL-271HR-C-TSL (MS ACCESS)
< FERRITE BEAD >
FB7501 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB7502 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB7503 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB7504 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
FB7505 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< FLUORESCENT INDICATOR TUBE >
FL7501 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< RESISTOR >
R7501 1-218-990-81 SHORT CHIP 0
R7502 1-218-942-11 RES-CHIP 120 5% 1/16W
R7503 1-218-942-11 RES-CHIP 120 5% 1/16W
R7504 1-218-942-11 RES-CHIP 120 5% 1/16W
R7505 1-218-942-11 RES-CHIP 120 5% 1/16W
R7506 1-218-990-81 SHORT CHIP 0
R7509 1-216-864-11 SHORT CHIP 0
R7510 1-218-953-11 RES-CHIP 1K 5% 1/16W
A-1214-520-A PD-291 BOARD, COMPLETE
***********************
< CAPACITOR >
C5701 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C5702 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C5703 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5704 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C5706 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5709 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5711 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5712 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5714 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C5715 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C5716 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C5717 1-137-700-11 TANTAL. CHIP 10uF 20% 6.3V
C5719 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5720 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5721 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C5722 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C5724 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5725 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5727 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C5728 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5729 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN5701 1-817-544-51 CONNECTOR, FPC (ZIF) 39P
* CN5702 1-818-246-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN5703 1-794-322-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN5704 1-785-905-51 CONNECTOR, FFC/FPC (ZIF) 24P
* CN5705 1-794-322-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN5706 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D5701 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D5702 8-719-083-91 DIODE EDZ TE61 6.8B
D5704 8-719-074-67 DIODE EDZ-TE61-5.6B
D5705 8-719-083-91 DIODE EDZ TE61 6.8B
D5706 8-719-083-91 DIODE EDZ TE61 6.8B
< FERRITE BEAD >
FB5701 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC5701 8-753-229-95 IC CXM3006CER-T4
< COIL >
* L5701 1-400-411-21 INDUCTOR 4.7uH
* L5702 1-400-411-21 INDUCTOR 4.7uH
* L5703 1-400-411-21 INDUCTOR 4.7uH
< TRANSISTOR >
Q5701 8-729-427-67 TRANSISTOR XP421F-TXE
Q5702 8-729-427-37 TRANSISTOR XP411F-TXE
Q5706 6-550-239-01 TRANSISTOR DTA144EMT2L
Q5707 8-729-054-48 TRANSISTOR UP04601008S0
Q5708 8-729-054-48 TRANSISTOR UP04601008S0
Q5709 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q5710 6-550-234-01 TRANSISTOR UNR32A300LS0
Q5711 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q5712 8-729-041-23 TRANSISTOR NDS356AP
< RESISTOR >
R5701 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R5703 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R5712 1-218-975-11 RES-CHIP 68K 5% 1/16W
R5714 1-218-949-11 RES-CHIP 470 5% 1/16W
R5715 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5716 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R5719 1-218-975-11 RES-CHIP 68K 5% 1/16W
R5720 1-208-934-11 METAL CHIP 91K 0.5% 1/16W
R5721 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R5723 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R5724 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5725 1-218-969-11 RES-CHIP 22K 5% 1/16W
R5726 1-218-950-11 RES-CHIP 560 5% 1/16W
R5730 1-218-969-11 RES-CHIP 22K 5% 1/16W
R5733 1-218-953-11 RES-CHIP 1K 5% 1/16W
MS-328 PD-291
To Next Page
