33
Menus
<VF OUT>
08 (U01)
VF OUT COLOR, Y, R, G, B,
(COLOR), (Y), (R), (G), (B),
(RET), (R+G), (R+B), (G+B)
Settings in ( ): When HDLA attached (cannot be
changed)
RET MIX VF ON, OFF
, (ON), (OFF) Settings in ( ): When HDLA attached (cannot be
changed)
MIX DIRECTION MAIN, RET
MIX VF MODE Y-MIX, WIRE(W), WIRE(B)
MIX VF LEVEL 0 to 80%
CHARACTER LEVEL 0 to 5, 4
<SWITCH ASSIGN1>
09 (U09)
GAIN
L:
–3, 0, 3, 6, 9, 12 dB
M:
–3, 0, 3, 6, 9, 12 dB
H:
–3, 0, 3, 6, 9, 12 dB
ASSIGNABLE1 UC model:
OFF
, RETURN1 SW, RETURN2
SW, INCOM, VF DETAIL, MIX VF,
5600K, FAN MAX,
D.EXTENDER, FOCUS ASSIST
INDICATOR, VF ASSIGN SW1,
VF ASSIGN SW2 - - -
CE model:
OFF
, RETURN1 SW, RETURN2
SW, ENG, PROD, VF DETAIL,
MIX VF, 5600K, FAN MAX,
D.EXTENDER, FOCUS ASSIST
INDICATOR, VF ASSIGN SW1,
VF ASSIGN SW2 - - -
---: When HDLA attached (HSC300RF/HSC300R only)
ASSIGNABLE2
ASSIGNABLE REAR UC model:
OFF
, RETURN1 SW, RETURN2
SW, INCOM, VF DETAIL, MIX VF,
5600K, FAN MAX,
D.EXTENDER, FOCUS ASSIST
INDICATOR, CURSOR,
MARKER, VF ASSIGN SW1,
VF ASSIGN SW2 - - -
CE model:
OFF
, RETURN1 SW, RETURN2
SW, ENG, PROD, VF DETAIL,
MIX VF, 5600K, FAN MAX,
D.EXTENDER, FOCUS ASSIST
INDICATOR, CURSOR,
MARKER, VF ASSIGN SW1,
VF ASSIGN SW2 - - -
ASSIGNABLE HDLA OFF
, EXTENDER, 5600K, FAN
MAX
Only when HDLA attached
RE.ROTATION STD
, RVS Specify operation mode of the menu control knob on
the front.
STD: Clockwise rotation moves the pointer down or
increases values on the menu screen.
RVS: Counterclockwise rotation moves the pointer
down or increases values on the menu screen.
Page name
Page No.
Item Settings Description
