46
Appendix
Triax Transmission Distances
When an HSC300R is connected to HSCU300R/
HSCU-300
The maximum and minimum transmission distances allowed
for triax cable connection are shown in the table below. The
distances may vary according to the conditions, such as the
total power requirements (including the power supply to the
camera from the CCU) and cable degradation.
Allowable transmission range when using triax cables with the
following characteristics:
Attenuation: 3.8 to 68.4 dB at 100 MHz (including the
connector loss)
1) If the transmission distance exceeds approximately 7/9 of the
maximum transmission distance, the teleprompter transmitted
image quality starts to deteriorate.
2) The maximum distance is 650 m (2133 ft) when the total power for
the lens, viewfinder and utility outputs is between 100 W and 120 W.
When an HSC300R is connected to HXCU-100 or
when an HSC100R is connected to HSCU300R/
HSCU-300/HXCU-100
The maximum and minimum transmission distances allowed
for triax cable connection are shown in the table below. The
distances may vary according to the conditions, such as cable
degradation.
Allowable transmission range when using triax cables with the
following characteristics:
Attenuation: 3.8 to 45.6 dB at 100 MHz (including the
connector loss)
Error Messages
If a problem occurs during operation, a warning message is
displayed.
To display a message, set the DISPLAY/MENU switch to
DISPLAY or MENU.
Using a USB Drive
You can connect a USB drive to the USB connector to save
and load the settings data file.
The following Sony USB drives are recommended.
(As of July 2013)
• USB drives other than those recommended may not be
recognized when connected to the USB connector.
• USB drives must be formatted with the FAT16 or FAT32 file
system. Recommended Sony USB drives are preformatted,
and can be used without any prior setup.
Specifications
Cable type (example) Max. distance
1)
Min. distance
Fujikura 8.5 mm dia. 900 m (2953 ft)
2)
50 m (164 ft)
Fujikura 14.5 mm dia. 1800 m (5906 ft) 100 m (328 ft)
Belden 9232 13.2 mm dia. 1300 m (4265 ft) 75 m (246 ft)
Cable type (example) Max. distance Min. distance
Fujikura 8.5 mm dia. 600 m (1969 ft) 50 m (164 ft)
Fujikura 14.5 mm dia. 1200 m (3937 ft) 100 m (328 ft)
Belden 9232 13.2 mm dia. 850 m (2789 ft) 75 m (246 ft)
Note
Message Meaning
TEMP WARNING The internal temperature is
extraordinarily high.
FAN STOP The built-in fan is not rotating properly.
SET SYSTEM CLOCK The time/date of the internal clock
have not been set.
OHB BLOCK NG! A problem is detected in the optical
block.
MSU RPN BUSY RPN compensation was attempted
using the camera menu while being
operated from an external device.
Consult Sony service personnel.
VF RPN BUSY RPN compensation was attempted
from an external device while being
operated using the camera menu.
Consult Sony service personnel.
FORMAT ERROR! A USB drive operation was attempted
with an unformatted drive.
FILE ERROR An error occurred while reading a file
from a USB drive.
OTHER MODEL’S FILE You attempted to read a file of other
models having no compatibility.
FILE NOT FOUND The file you attempted to read does
not exist on the USB drive.
Series Product
Micro Vault P USM32GP, USM16GP
Micro Vault M USM32GM, USM16GM, USM8GM, USM4GM
Micro Vault R USM32GR, USM16GR, USM8GR, USM4GR
Notes
General
Power supply 180 V DC, 1.0 A (max.)
12 V DC, 7 A (max.)
Operating temperature –20 °C to +45 °C (–4 °F to +113 °F)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Mass Approx. 4.1 kg (9 lb 0.62 oz)
(HSC300RF/HSC100RF, unit only)
Approx. 4.5 kg (9 lb 15 oz)
(HSC300R/HSC100R, unit only)
Imager
Imager 2/3-type Progressive Scan CCD
Method 3-CCD, RGB
Effective resolution 1920 (horizontal) × 1080 (vertical)
Message Meaning
To Next Page
