Overview
System Configuration Example
Peripheral devices and related devices for the camera are
shown in the following diagrams.
Production of some of the peripheral devices and related
devices shown in the figures may have been discontinued. For
advice on choosing devices, please contact your Sony dealer
or a Sony sales representative.
Standalone operation example
Note
1
HSC300RF/HSC100RF
HSC300R/HSC100R
HDVF-200/C35W
Viewfinder
Lens (for ENG/EFP)
VCT-14
Tripod Adapter
Tripod for
portable camera
RCP-1000 series
Remote Control Panel
CCA-5 cable
AC-DN10/DN2B
AC Adapter
BC-L70/L160
Battery Charger
Video output
HD-SDI/SD-SDI/VBS
1)
(selectable)
AC power
CAC-12
Microphone Holder
Microphone RM-B750/B170
Remote Control Unit
1) A subcarrier phase-lock function for
external reference is not available on
the VBS signal output from the camera.
USB drive
