43
GB
Additional Information
1280 × 720p 29.97/30 Hz
Frame packing
Side-by-Side (Half)
Over-Under
(Top-and-Bottom)
Deep Colour: 30bit/36bit
Audio inputs BD/DVD, GAME, SAT/
CATV: See “Formats
supported by this system”
(page 42).
Tuner section
System PLL quartz-locked digital
synthesizer
FM tuner section
Tuning range 87.5 - 108.0 MHz
(50 kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Speaker (SS-TSB105)
Front speaker unit
Speaker system Bass Reflex
Speaker unit 55 mm × 80 mm, cone type
× 2
Rated impedance 3 ohms
Dimensions (approx.) 85 mm × 220 mm × 95 mm
(with foot) (w/h/d)
Mass (approx.) 0.46 kg (with foot)
Speaker cords 3 m
Subwoofer (SA-WFS30)
Speaker system Subwoofer, Bass reflex
Speaker unit 130 mm cone type
Rated impedance 3 ohms
Dimensions (approx.) 175 mm × 325 mm ×
368 mm (w/h/d)
Mass (approx.) 7.5 kg
General
Power requirements 220 V -240 V AC,
50/60 Hz
Power consumption
On: 75 W
Standby mode: 0.4 W or less
Design and specifications are subject to change without
notice.
• Standby power consumption 0.4 W or less.
• Over 85 % power efficiency of amplifier block is
achieved with the full digital amplifier, S-Master.
