SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•Abbreviation
JE: Tourist model
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
ICD-MS525
When indicating parts by reference number,
please include the board name.
AUDIO
* A-3021-995-A AUDIO BOARD, COMPLETE
**********************
3-236-032-01 CUSHION, MICROPHONE
3-238-335-01 SHEET (SPK), INSULATING
3-240-258-01 SHEET (TERMINAL), INSULATING
< CAPACITOR >
C1202 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C1203 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C1204 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C1206 1-127-895-11 TANTAL. CHIP 22uF 20% 4V
C1207 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C1208 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C2202 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C2203 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C2204 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C2206 1-127-895-11 TANTAL. CHIP 22uF 20% 4V
C2207 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C2208 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C3201 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3202 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3203 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3204 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3205 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3206 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3207 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3208 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3209 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3210 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3212 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C3215 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V
C3218 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3219 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3220 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3221 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3223 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C3225 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3226 1-127-988-11 CERAMIC CHIP 15000PF 10% 16V
C3227 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C3228 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3229 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C3230 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C3231 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3232 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3233 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3234 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3235 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3236 1-131-862-11 TANTAL. CHIP 47uF 20% 4V
C3237 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C3238 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C3239 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C3240 1-164-940-11 CERAMIC CHIP 0.0033uF 10.00% 16V
C3241 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C3242 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C5201 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C5202 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C5203 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C5204 1-128-964-11 TANTAL. CHIP 100uF 20% 6.3V
C5205 1-128-964-11 TANTAL. CHIP 100uF 20% 6.3V
C5206 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C5207 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C5208 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V
C5209 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V
C6201 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C6203 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C6204 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C6205 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C6206 1-117-919-11 TANTAL. CHIP 10uF 20.00% 6.3V
C6207 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6208 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C6211 1-164-931-11 CERAMIC CHIP 100PF 10.00% 50V
C6212 1-164-931-11 CERAMIC CHIP 100PF 10.00% 50V
C6213 1-164-931-11 CERAMIC CHIP 100PF 10.00% 50V
< FERRITE BEAD >
FB1201 1-469-084-21 FERRITE 1MH
FB2201 1-469-084-21 FERRITE 1MH
FB3201 1-469-084-21 FERRITE 1MH
FB3202 1-469-084-21 FERRITE 1MH
FB3203 1-469-084-21 FERRITE 1MH
< IC >
IC3201 6-701-663-01 IC AN12906A
IC3202 6-701-665-01 IC S1V81510F0020B
IC5201 6-701-028-01 IC XC61CN1402NR
IC5202 6-701-806-01 IC XC62FP3102MR
IC5203 6-701-803-01 IC XC62FP2502MR
@ IC6201 6-801-067-01 IC uPD77213F1-004-DA2
IC6202 6-701-750-01 IC XC25BS5107MR
IC6203 6-701-666-01 IC M25P05-VMN6T
@ Replacement of IC6201 used in this
set requires a special tool.
