Sony ICD-MS525 - Eject Mecha Block Assy, MAIN Board

6
ICD-MS525
2-3. EJECT MECHA BLOCK ASSY, MAIN BOARD
qg MAIN board
qd sheet (SD-A)
8 connector
(CN7103) (10 core)
4 connector
(CN7104) (8 core)
7 connector
CN7201
CN7101
q; Remove the soldering.
qs Remove the soldering.
5 Remove the soldering.
9 eject mecha block assy
qa shield paper (E)
6 claw
1 ornament (MIC)
2 two screws (B 1.7 × 8)
3 ground plate
qf insulating sheet (JACK)
