NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-678-893-11 AC IN BOARD
***********
0 ACJ401 1-526-838-11 INLET, AC 2P(- AC IN)
**************************************************************
* 1-678-894-11 AMPLIFIER BOARD
***************
< CAPACITOR >
C601 1-104-665-11 ELECT 100uF 20% 10V
C602 1-104-665-11 ELECT 100uF 20% 10V
C603 1-126-964-11 ELECT 10uF 20% 50V
C604 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C605 1-104-665-11 ELECT 100uF 20% 10V
C606 1-104-665-11 ELECT 100uF 20% 10V
C607 1-115-156-11 CERAMIC CHIP 1uF 10V
C608 1-126-929-11 ELECT 4700uF 20% 10V
C609 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C610 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C611 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C612 1-165-128-11 CERAMIC CHIP 0.22uF 16V
< CONNECTOR >
* CN601 1-568-270-11 SOCKET, CONNECTOR 4P
* CN602 1-568-268-11 SOCKET, CONNECTOR 2P
< IC >
IC601 8-759-802-46 IC LA4550
< RESISTOR >
R601 1-216-813-11 METAL CHIP 220 5% 1/16W
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R604 1-216-813-11 METAL CHIP 220 5% 1/16W
R605 1-216-837-11 METAL CHIP 22K 5% 1/16W
R606 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R607 1-216-789-11 METAL CHIP 2.2 5% 1/16W
**************************************************************
* A-3683-227-A KEY BOARD, COMPLETE
********************
3-047-925-01 HOLDER (LED)
< CAPACITOR >
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D301 8-719-080-08 LED SLP145B-51(TUNE)
D302 8-719-080-08 LED SLP145B-51(FM1)
D303 8-719-080-08 LED SLP145B-51(FM3)
D304 8-719-080-08 LED SLP145B-51(FM2)
< JUMPER >
JC301 1-216-296-91 SHORT 0
JC302 1-216-296-91 SHORT 0
JC303 1-216-864-11 METAL CHIP 0 5% 1/16W
< RESISTOR >
R301 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R303 1-216-821-11 METAL CHIP 1K 5% 1/16W
R304 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-821-11 METAL CHIP 1K 5% 1/16W
R306 1-216-821-11 METAL CHIP 1K 5% 1/16W
R307 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
SW301 1-692-444-11 SWITCH, KEY BOARD(FM1)
SW302 1-692-444-11 SWITCH, KEY BOARD(FM2)
SW303 1-692-444-11 SWITCH, KEY BOARD(FM3)
SW304 1-692-444-11 SWITCH, KEY BOARD(MANUAL)
**************************************************************
* A-3683-226-A MAIN BOARD, COMPLETE
*********************
3-043-346-01 HOLDER, FERRITE-ROD ANTENNA
3-220-210-01 CHASSIS, SUB
7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
AC IN AMPLIFIER
KEY MAIN
