Sony ICF-1000L - 2-3. AC IN Board, AMP Board; 2-4. Main Board, Key Board

– 5 –
2-3. AC IN BOARD, AMP BOARD
2-4. MAIN BOARD, KEY BOARD
4 Screw (+BTP 3x20
)
Holder
AC IN board
1 Screws (+BTP 2.6x10)
5 Claws
6
3
2
7
CN602
AMP board
Cabinet (front)
5 Screws (+BTP 2.6x6)
3 Screws
(+BTP 3x10)
9 Screws (+BTP 3x10)
9 Screws (+BTP 3x10)
8 Remove solder
7 CN201
q; Claw
q; Claw
1 Knob (tone)
1 Knob (tuning)
q; Claws
6
qa
4
2 Wind up thread,
and pull it up
Thread
Knob (band)
key board
Main board
Chassis
Cabinet (front)
