Sony ICF-1000L - Setting the Pointer

– 6 –
3
4
2
A
1
Rack (pointer)
Gear, VOL
Pointer
Pointer
Rack (pointer)
Scribed
line
Chassi
s
Drum (A)
Drum (B)
2-5. SETTING THE POINTER
1 Turn the drum (B) in the direction of A until it stopped.
2 Insert the rack (pointer) into the chassis groove.
3 Install the pointer .
4 Slid the pointer and align it with the groove on the scribed
"Gear , VOL" enga g es with
drum (A) like a figure.
