– 24 –
ICF-1000L
9-927-976-11
Sony Corporation
Audio Entertainment Group
2000G0244-1
Printed in Japan © 2000.7
Published by PE General Engineering Dept.
R221 1-216-833-11 METAL CHIP 10K 5% 1/16W
R501 1-216-821-11 METAL CHIP 1K 5% 1/16W
R502 1-216-833-11 METAL CHIP 10K 5% 1/16W
R503 1-216-833-11 METAL CHIP 10K 5% 1/16W
R505 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R506 1-216-844-11 METAL CHIP 82K 5% 1/16W
R507 1-216-833-11 METAL CHIP 10K 5% 1/16W
R508 1-216-833-11 METAL CHIP 10K 5% 1/16W
R509 1-216-833-11 METAL CHIP 10K 5% 1/16W
R510 1-216-817-11 METAL CHIP 470 5% 1/16W
R511 1-216-837-11 METAL CHIP 22K 5% 1/16W
R512 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R513 1-216-833-11 METAL CHIP 10K 5% 1/16W
R514 1-216-853-11 METAL CHIP 470K 5% 1/16W
R515 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VARIABLE RESISTOR >
RV201 1-241-377-11 RES, VAR, CARBON 100K(FM3)
RV202 1-241-377-11 RES, VAR, CARBON 100K(FM1)
RV203 1-241-377-11 RES, VAR, CARBON 100K(FM2)
RV204 1-241-765-11 RES, ADJ, CARBON 22K(FM VT VOLTAGE)
RV205 1-223-621-11 RES, VAR, CARBON 100K(FM TUNING)
RV501 1-227-240-11 RES, VAR, CARBON 100K(TONE)
RV502 1-225-498-11 RES, VAR, CARBON 50K(VOLUME)
< SWITCH >
S1 1-571-172-21 SWITCH, SLIDE(BAND)
< TRANSFORMER >
T1 1-404-902-11 TRANSFORMER, IF (MW IF)
< VIBRATOR >
X201 1-579-452-11 OSCILLATOR, CERAMIC(3.68MHz)
**************************************************************
* 1-678-892-11 POWER BOARD
*************
< CAPACITOR >
C401 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-126-927-11 ELECT 2200uF 20% 10V
C403 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C405 1-126-925-11 ELECT 470uF 20% 10V
C406 1-126-925-11 ELECT 470uF 20% 10V
C407 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN401 1-568-269-11 SOCKET, CONNECTOR 3P
CN405 1-568-269-11 SOCKET, CONNECTOR 3P
< DIODE >
D401 8-719-031-85 DIODE 1N4002L
D402 8-719-031-85 DIODE 1N4002L
D403 8-719-031-85 DIODE 1N4002L
D404 8-719-031-85 DIODE 1N4002L
< JACK >
EPJ401 1-566-891-21 JACK (v)
< JUMPER >
JC402 1-216-296-91 SHORT 0
< COIL >
L401 1-410-294-11 INDUCTOR 38uH
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-805-11 METAL CHIP 47 5% 1/16W
R403 1-216-805-11 METAL CHIP 47 5% 1/16W
R404 1-216-809-11 METAL CHIP 100 5% 1/16W
R405 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S401 1-571-042-11 SWITCH, PUSH (1 KEY)(OPERATION)
**************************************************************
MISCELLANEOUS
*************
SP1 1-529-803-11 SPEAKER (10.3cm)
ANT1 1-501-222-71 ANTENNA, TELESCOPIC (FM)
T401 1-435-504-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-696-562-11 CORD, POWER (AEP)
0 1-751-115-11 CORD, POWER (UK)
3-049-016-11 MANUAL, INSTRUCTION(ENGLISH,FRENCH,
GERMAN,SPANISH,ITALIAN,DUTCH,SWEDISH,
PORTUGUESE,FINNISH,DANISH)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-623-508-01 LUG, 3
#2 7-671-112-11 BALL, STEEL
#3 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#4 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#5 7-685-535-19 SCREW +BTP 2.6X10 TYPE2 N-S
#6 7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
#7 7-685-551-14 SCREW +BTP 3X20 TYPE2 N-S
#8 7-685-903-11 SCREW +PTPWH 3X6 (TYPE2)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
MAIN POWER
