18
ICF-C630
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3347-866-A KEY (LEFT) BOARD, COMPLETE
**************************
< SWITCH >
S101 1-786-050-21 SWITCH, KEYBOARD (TIME SET –)
S102 1-786-050-21 SWITCH, KEYBOARD (TIME SET +)
S103 1-786-050-21 SWITCH, KEYBOARD (CLOCK/
D.S.T. SUMMER T.)
*************************************************************
KEY (RIGHT) BOARD
*****************
< JUMPER RESISTOR >
JC117 1-216-864-11 METAL CHIP 0 5% 1/10W
< RESISTOR >
R162 1-216-845-11 METAL CHIP 100K 5% 1/10W
R163 1-216-845-11 METAL CHIP 100K 5% 1/10W
R164 1-216-845-11 METAL CHIP 100K 5% 1/10W
< SWITCH >
S108 1-786-050-21 SWITCH, KEYBOARD (BAND)
S109 1-786-050-21 SWITCH, KEYBOARD (SLEEP)
S110 1-786-050-21 SWITCH, KEYBOARD (NAP ON/OFF)
*************************************************************
* A-3347-982-A MICROCOMPUTER BOARD, COMPLETE
********************************
3-248-608-01 HOLDER (LCD)
3-254-545-01 SHEET (LCD)
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C107 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C108 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C109 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C110 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C111 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C112 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C113 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C117 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C118 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C119 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C120 1-125-701-11 DOUBLE LAYERS 0.047F 5.5V
C121 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C122 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C123 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C124 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C125 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C126 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C127 1-115-156-11 CERAMIC CHIP 1uF 10V
C128 1-115-156-11 CERAMIC CHIP 1uF 10V
C129 1-115-156-11 CERAMIC CHIP 1uF 10V
C130 1-115-156-11 CERAMIC CHIP 1uF 10V
C131 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C132 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C133 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C134 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
< DIODE >
D101 6-500-203-01 LED TLGE262(NP) (LCD BACK LIGHT)
D102 6-500-203-01 LED TLGE262(NP) (LCD BACK LIGHT)
D103 6-500-203-01 LED TLGE262(NP) (LCD BACK LIGHT)
D104 8-719-071-34 DIODE RB521S-30-TE61
D105 8-719-071-34 DIODE RB521S-30-TE61
D106 8-719-069-29 DIODE RB520S-30-TE61
D107 8-719-988-61 DIODE 1SS355TE-17
D108 8-719-988-61 DIODE 1SS355TE-17
D109 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC101 8-759-565-57 IC XC62FP2202PR
IC102 6-703-784-01 IC XC61CN2302NR
IC103 6-702-084-01 IC XC61CN2102NR
IC104 6-702-083-01 IC XC61CN1902NR
IC105 6-803-068-01 IC uPD789488GC-A23-8BT
IC106 6-702-590-01 IC XC61CN1702NR
< JUMPER RESISTOR >
JC101 1-216-864-11 METAL CHIP 0 5% 1/10W
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
MICROCOMPUTER
KEY (RIGHT)KEY (LEFT)
