19
ICF-C630
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JC102 1-216-864-11 METAL CHIP 0 5% 1/10W
JC103 1-216-864-11 METAL CHIP 0 5% 1/10W
JC104 1-216-864-11 METAL CHIP 0 5% 1/10W
JC105 1-216-864-11 METAL CHIP 0 5% 1/10W
JC106 1-216-864-11 METAL CHIP 0 5% 1/10W
JC107 1-216-864-11 METAL CHIP 0 5% 1/10W
JC108 1-216-864-11 METAL CHIP 0 5% 1/10W
JC109 1-216-864-11 METAL CHIP 0 5% 1/10W
JC110 1-216-864-11 METAL CHIP 0 5% 1/10W
JC111 1-216-864-11 METAL CHIP 0 5% 1/10W
JC113 1-216-864-11 METAL CHIP 0 5% 1/10W
JC114 1-216-864-11 METAL CHIP 0 5% 1/10W
< LIQUID CRYSTAL DISPLAY >
LCD101 1-805-186-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R130 1-216-857-11 METAL CHIP 1M 5% 1/10W
R131 1-216-857-11 METAL CHIP 1M 5% 1/10W
R132 1-216-857-11 METAL CHIP 1M 5% 1/10W
R133 1-216-833-11 METAL CHIP 10K 5% 1/10W
R134 1-216-833-11 METAL CHIP 10K 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R137 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R138 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R139 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R140 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R141 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R142 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R143 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R144 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R145 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R146 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R147 1-216-849-11 METAL CHIP 220K 5% 1/10W
R148 1-216-797-11 METAL CHIP 10 5% 1/10W
R149 1-216-833-11 METAL CHIP 10K 5% 1/10W
R151 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R153 1-216-809-11 METAL CHIP 100 5% 1/10W
R155 1-216-797-11 METAL CHIP 10 5% 1/10W
R156 1-216-797-11 METAL CHIP 10 5% 1/10W
R157 1-216-857-11 METAL CHIP 1M 5% 1/10W
R158 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R159 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R160 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R161 1-216-849-11 METAL CHIP 220K 5% 1/10W
< SWITCH >
S104 1-572-697-11 SWITCH, TACTILE (RADIO ON/OFF)
S105 1-786-050-21 SWITCH, KEYBOARD (ALARM B MELODY)
S106 1-572-697-11 SWITCH, TACTILE (BACKLIGHT•
SNOOZE/SLEEP OFF)
S107 1-786-050-21 SWITCH, KEYBOARD (ALARM A RADIO)
< VIBRATOR >
X101 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X102 1-579-901-11 VIBRATOR, CERAMIC (4.19MHz)
*************************************************************
* A-3347-871-A TUNER BOARD, COMPLETE
***********************
3-248-609-01 HOLDER (ANT)
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
< BPF >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C2 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C4 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C6 1-162-996-11 CERAMIC CHIP 7PF 0.5PF 50V
C7 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C8 1-126-157-11 ELECT 10uF 20% 16V
C9 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C10 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C11 1-126-160-11 ELECT 1uF 20% 50V
C12 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-124-259-11 ELECT 4.7uF 20% 16V
C15 1-126-157-11 ELECT 10uF 20% 16V
C16 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C17 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C18 1-126-157-11 ELECT 10uF 20% 16V
C19 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C20 1-126-935-11 ELECT 470uF 20% 10V
C21 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C22 1-126-934-11 ELECT 220uF 20% 10V
C23 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C27 1-162-939-11 CERAMIC CHIP 8PF 0.5PF 50V
C29 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C30 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C33 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C35 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C36 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< FILTER >
CF1 1-781-861-71 FILTER, CERAMIC (COMBINATION)
CF2 1-781-861-71 FILTER, CERAMIC (COMBINATION)
CF3 1-781-790-11 FILTER, AM CERAMIC
< CONNECTOR >
* CN1 1-568-273-11 SOCKET, CONNECTOR 7P
* CN2 1-568-268-11 SOCKET, CONNECTOR 2P
< VARIABLE CAPACITOR >
CT1-4 1-141-681-11 CAP, VAR
CV1 1-141-681-11 CAP, VAR (TUNE)
< DIODE >
D1 8-719-069-29 DIODE RB520S-30-TE61
D5 8-719-069-29 DIODE RB520S-30-TE61
MICROCOMPUTER TUNER
