20
ICF-C630
Ref. No. Part No. Description Remark
< IC >
IC1 8-752-037-02 IC CXA1019S
IC2 6-704-101-01 IC XC6201P382PR
< JACK >
J1 1-580-681-21 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< JUMPER RESISTOR >
JC2 1-216-295-11 SHORT CHIP 0
< COIL >
L1 1-456-344-11 COIL, FERRITE-ROD ANTENNA (AM)
L2 1-424-793-11 COIL, AIR-CORE
L3 1-428-229-11 COIL, AIR-CORE
L4 1-456-345-11 COIL, AM OSC
L5 1-410-294-31 INDUCTOR 38uH
< TRANSISTOR >
Q1 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q2 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q3 6-550-044-01 TRANSISTOR 2SB1689-T106
Q4 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q5 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
Q6 8-729-029-03 TRANSISTOR DTC123EUA-T106
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4 1-216-805-11 METAL CHIP 47 5% 1/10W
R5 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R7 1-216-817-11 METAL CHIP 470 5% 1/10W
R8 1-216-845-11 METAL CHIP 100K 5% 1/10W
R9 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R10 1-216-817-11 METAL CHIP 470 5% 1/10W
R11 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R12 1-216-797-11 METAL CHIP 10 5% 1/10W
R14 1-216-833-11 METAL CHIP 10K 5% 1/10W
R15 1-216-841-11 METAL CHIP 47K 5% 1/10W
R17 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-228-790-00 RES, VAR, CARBON 50K (VOL)
< TRANSFORMER >
T1 1-439-678-11 TRANSFORMER, IF
< WIRE ANTENNA >
W1 1-754-135-11 ANTENNA (WIRE) (FM)
*************************************************************
ACCESSORIES
************
0 1-477-830-11 ADAPTOR, AC (AC-E45TR1)
3-249-145-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
GERMAN,SPANISH,DUTCH)
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
TUNER
