- 3 -

WAX3F

RM-ED009

The circuit boards used in these models have been processed using

Lead Free Solder. The boards are identified by the LF logo located

close to the board designation e.g. F1, H1 etc [ see examples ]. The

servicing of these boards requires special precautions to be taken as

outlined below.

Lead Free Soldered Boards

example 1

example 2

rebmuntraP retemaiD skrameR

91-500-046-7mm3.0gK52.0

02-500-046-7mm4.0gK05.0

12-500-046-7mm5.0gK05.0

22-500-046-7mm6.0gK52.0

32-500-046-7mm8.0gK00.1

42-500-046-7mm0.1gK00.1

52-500-046-7mm2.1gK00.1

62-500-046-7mm6.1gK00.1

CAUTION

SECTION 1 GENERAL

Lead Free Solder material must be used to comply with environmental requirements of new solder joints. Lead Free Solder is available under

the following part numbers :

Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires

soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.

For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com
