KLV-20/32/37/40S400A (CH) 1-5
1-2. KLV-37S400A
1-2-1. REAR COVER ASSY AND STAND ASSY REMOVAL
4 Two screws
(+PSW M3X5)
2 Four screws
(+PSW M5x12)
1 Five screws
(+BVTP2 4X16)
1 Two screws
(+BVTP2 4X16)
1 Four screws
(+BVTP2 4X16)
1 Four screws
(+BVTP2 4X16)
3 Two screws
(+BV 3X12)
5 Rear cover assy
8 Switch unit
6 Three screws
(+PSW M5X16)
7 Stand assy
