KLV-20/32/37/40S400A (CH) 3-9
KLV-40S400A
3-3-2. CHASSIS-1
REF. No. PART No. DESCRIPTION MARK REF. No. PART No. DESCRIPTION MARK
351 1-480-851-11 SWITCH UNIT
352 ! 1-821-909-11 AC INLET
353 2-596-649-01 +KTT 3X10 (S TYPE)
354 3-297-553-01 BRACKET, AC INLET
355 2-580-629-01 SCREW, +BVST 3X8
356 3-297-539-11 BRACKET, SIDE JACK
357 3-876-478-01 COVER, MS
358
A-1544-078-A BG1 MOUNT
359 2-580-626-01 SCREW, SP 4-4O UNC
360 ! A-1511-380-C IP5 COMPLE
361 * 1-835-147-11 CONNECTOR ASSY, MDF61
362 ! X-2318-764-1 COVER, UNDER (40) ASSY
363 1-966-106-21 HARNESS WITH CONNECTOR (LVDS)
351
355
355
355
360
355
362
353
352
354
361
355
358
355
359
355
357
356
355
355
355
355
363
