KLV-20/32/37/40S400A (CH) 1-11
KLV-40S400A
1-3-2. BG1 AND IP5 BOARDS REMOVAL
1-3-3. AC INLET AND UNDER COVER REMOVAL
1 Three screws
(+BVST 3X8)
1 Three screws
(+BVST 3X8)
2 IP5 board
Claw
Claw
5 Bracket side jack assy
8 One screw
(+BVST 3X8)
3 One screw
(+BVST 3X8)
8 One screw
(+BVST 3X8)
6 Three screws
(+BVST 3X8)
6 Five screws
(+BVST 3X8)
7 BG1 board
9 Main bracket
4 Harness with connector
5 One screw
(+BVST 3X8)
3 Two screws
(+KTT 3X10)
1 One screw
(+BVST 3X8)
2 Under cover (L2)
4 AC inlet
6 AC inlet bracket
