KLV-20/32/37/40S400A (CH) 1-10
1-3. KLV-40S400A
1-3-1. REAR COVER ASSY AND STAND ASSY REMOVAL
5 Two screws
(+PSW M3X5)
4 Four screws
(+PSW M5X16)
3 Five screws
(+BVTP2 4X16)
3 Two screws
(+BVTP2 4X16)
3 Four screws
(+BVTP2 4X16)
3 Four screws
(+BVTP2 4X16)
6 Two screws
(+BV 3X12)
7 Rear cover assy
8 Switch unit
1 Three screws
(+PSW M5X16)
2 Stand assy
