KLV-20/32/37/40S400A (CH) 1-4
KLV-32S400A
1-1-5. SPEAKER AND HG4 BOARD REMOVAL
3 Two screws
(+BV 3X12)
2 Loudspeaker
1 Loudspeaker
5 Light guide
4 HG4 board
Claws
1-1-6. LCD PANEL REMOVAL
2 Two screws
(+BVTP2 4X16)
3 LCD panel
1 Harness with connector
(LVDS)
4 Bezel assy
