KLV-20/32/37/40S400A (CH) 1-12
KLV-40S400A
1-3-4. FRAME REMOVAL
qf Bottom frame
assy
6 Spine frame assy
qs Spine frame
assy
1 Two screws
(+PSW M5X8)
5 Three screws
(+PSW M4X8)
qa Three screws
(+PSW M4X8)
7 Two screws
(+PSW M5X8)
4 Vesa frame (BTM)
assy
0 Vesa frame (BTM)
assy
2 Vesa frame (TOP)
8 Vesa frame
(TOP)
3 Two screws
(+PSW M5X8)
9 Two screws
(+PSW M5X8)
qd Four screws
(+BVTP2 4X16)
