Sony KV-21FA210 TRINITRON - Page 46

— 46 —
KV-21FA210
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
C207 1-126-963-11 ELECT 4.7µF 20% 50V
C212 1-126-963-11 ELECT 4.7µF 20% 50V
C213 1-126-963-11 ELECT 4.7µF 20% 50V
C220 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C301 1-126-956-91 ELECT 0.1µF 20% 50V
C302 1-126-956-91 ELECT 0.1µF 20% 50V
C303 1-126-956-91 ELECT 0.1µF 20% 50V
C304 1-126-956-91 ELECT 0.1µF 20% 50V
C305 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C306 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C307 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C312 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C313 1-126-956-91 ELECT 0.1µF 20% 50V
C325 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C326 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C328 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C330 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C337 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C351 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C360 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C361 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C362 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C363 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C370 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C390 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C400 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C401 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C402 1-164-174-11 CERAMIC CHIP 0.0082µF 10% 25V
C403 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C404 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C405 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C406 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C407 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
C408 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
C409 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C410 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C411 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C412 1-126-960-11 ELECT 1µF 20% 50V
C413 1-126-960-11 ELECT 1µF 20% 50V
C414 1-126-961-11 ELECT 2.2µF 20% 50V
C415 1-126-960-11 ELECT 1µF 20% 50V
C416 1-126-960-11 ELECT 1µF 20% 50V
C418 1-126-963-11 ELECT 4.7µF 20% 50V
C420 1-126-960-11 ELECT 1µF 20% 50V
C422 1-126-960-11 ELECT 1µF 20% 50V
C440 1-126-940-11 ELECT 330µF 20% 25V
C441 1-126-940-11 ELECT 330µF 20% 25V
C470 1-126-935-11 ELECT 470µF 20% 16V
C498 1-126-960-11 ELECT 1µF 20% 50V
C499 1-126-963-11 ELECT 4.7µF 20% 50V
C502 1-102-112-00 CERAMIC 330pF 10% 50V
C503 1-106-383-00 MYLAR 0.047µF 10% 200V
C504 1-249-426-11 CARBON 5.6K 5% 1/4W
C505 1-102-002-00 CERAMIC 680pF 10% 500V
! C506 1-117-214-11 CERAMIC 0.001µF 10% 2KV
! C507 1-117-642-11 FILM 8200pF 3% 1.2KV
! C508 1-129-722-00 FILM 0.047µF 5% 630V
C509 1-128-551-11 ELECT 22µF 20% 63V
C510 1-117-214-11 CERAMIC 0.001µF 10% 2KV
C511 1-115-521-11 FILM 0.82µF 5% 250V
C512 1-104-987-11 MYLAR 0.001µF 5% 200V
C513 1-106-383-00 MYLAR 0.047µF 10% 200V
C514 1-115-519-11 FILM 0.56µF 5% 250V
C515 1-107-651-11 ELECT 4.7µF 20% 250V
C520 1-126-965-91 ELECT 22µF 20% 50V
C521 1-126-960-11 ELECT 1µF 20% 50V
C522 1-162-117-00 CERAMIC 100pF 10% 500V
C523 1-136-346-51 MYLAR 0.22µF 20% 125V
(LATIN NORTH ONLY)
C523 1-136-346-61 MYLAR 0.22µF 20% 300V
(LATIN SOUTH ONLY)
C525 1-164-646-11 CERAMIC 2200pF 10% 500V
C526 1-102-244-00 CERAMIC 220pF 10% 500V
C527 1-107-645-11 ELECT 22µF 20% 200V
C529 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C534 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C536 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C537 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C539 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C542 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C544 1-126-967-11 ELECT 47µF 20% 50V
C545 1-126-969-11 ELECT 220µF 20% 50V
C546 1-137-194-81 FILM 0.47µF 5% 50V
C551 1-126-960-11 ELECT 1µF 20% 50V
C552 1-126-964-11 ELECT 10µF 20% 50V
C553 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C554 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
! C561 1-126-963-11 ELECT 4.7µF 20% 50V
