SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
When indicating parts by reference
number, please include the board.
• Abbreviation
EE : East European model
MX : Mexican model
E : Indication of country of origin
1E : No indication of country of origin
A-3021-216-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-104-400-21 ELECT 47uF 20% 4V
C102 1-104-396-11 ELECT 10uF 20% 16V
C103 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C104 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C105 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C106 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C107 1-104-396-11 ELECT 10uF 20% 16V
C108 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C109 1-162-638-11 CERAMIC CHIP 1uF 16V
C110 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C111 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C112 1-104-396-11 ELECT 10uF 20% 16V
C113 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C115 1-104-400-21 ELECT 47uF 20% 4V
C116 1-164-346-11 CERAMIC CHIP 1uF 16V
C117 1-164-346-11 CERAMIC CHIP 1uF 16V
C118 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C119 1-104-400-21 ELECT 47uF 20% 4V
C120 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C122 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C123 1-104-402-11 ELECT 220uF 20% 4V
C124 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C127 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C129 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C601 1-126-153-11 ELECT 22uF 20% 6.3V
C602 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C603 1-126-153-11 ELECT 22uF 20% 6.3V
< JACK >
CN101 1-580-372-41 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 3V)
< DIODE >
D102 8-719-062-18 LED SHR17D-TNBO (BATT)
< IC >
IC101 8-759-339-54 IC NJM-2128M-TE2
IC601 8-759-804-43 IC LA5521M
< JACK >
J101 1-785-791-11 JACK (EAR)
< JUMPER RESISTOR >
JC1 1-216-295-00 SHORT 0
JC2 1-216-295-00 SHORT 0
JC3 1-216-295-00 SHORT 0
JC4 1-216-296-00 SHORT 0
JC5 1-216-296-00 SHORT 0
JC6 1-216-296-00 SHORT 0
JC7 1-216-296-00 SHORT 0
JC8 1-216-296-00 SHORT 0
JC9 1-216-296-00 SHORT 0
JC10 1-216-296-00 SHORT 0
JC11 1-216-296-00 SHORT 0
JC12 1-216-296-00 SHORT 0
JC13 1-216-295-00 SHORT 0
JC14 1-216-295-00 SHORT 0
JC15 1-216-295-00 SHORT 0
JC16 1-216-296-00 SHORT 0
JC17 1-216-296-00 SHORT 0
< RESISTOR >
R101 1-216-037-00 METAL CHIP 330 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R103 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R104 1-216-121-00 RES,CHIP 1M 5% 1/10W
R105 1-216-009-00 RES,CHIP 22 5% 1/10W
R106 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R107 1-216-218-00 RES,CHIP 6.8K 5% 1/8W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-234-00 RES,CHIP 33K 5% 1/8W
R110 1-216-077-00 METAL CHIP 15K 5% 1/10W
R111 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R112 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R113 1-216-045-00 METAL CHIP 680 5% 1/10W
R114 1-216-013-00 METAL CHIP 33 5% 1/10W
R115 1-216-037-00 METAL CHIP 330 5% 1/10W
R116 1-216-194-00 METAL CHIP 680 5% 1/8W
R121 1-216-009-00 RES,CHIP 22 5% 1/10W
R122 1-216-190-00 RES,CHIP 470 5% 1/8W
R123 1-216-089-00 RES,CHIP 47K 5% 1/10W
R124 1-216-057-11 RES,CHIP 2.2K 5% 1/10W
To Next Page
