Sony m-430 - LID, BATTERY CASE; CABINET (REAR) ASSY

– 5 –
2-3. CABINET (REAR) ASSY
Note : When installing, fit the knobs and switches.
2-2. LID, BATTERY CASE
3 claws
5 lid, battery case
2
1
2
1 screw (1.7x16)
3 screw (B1.7x5), tapping
2 screw (1.7x16)
5 claw
4 claws
switch
knob
6 cabinet (rear) assy
