55
Tape player section
Recording system 4-track 2-channel stereo
Frequency response 40 – 13,000 Hz (±3 dB),
(DOLBY NR OFF) using Sony TYPE I
cassette
40 – 14,000 Hz (±3 dB),
using Sony TYPE II
cassette
Wow and flutter ±0.15% W.Peak (IEC)
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
*Tuning range 87.5 – 108.0 MHz
Antenna FM lead antenna
Antenna terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
*FM Tuning range for Japan tourist model:
Tuning range 76.5 – 108.0 MHz
AM tuner section
Tuning range
2 Band type: 531 – 1,602 kHz
(with the interval set at 9
kHz)
530 – 1,710 kHz
(with the interval set at 10
kHz)
3 Band type:
Middle Eastern models:
MW: 531 – 1,602 kHz
(with the interval set at 9
kHz)
SW: 5.95 – 17.90 MHz
(with the interval set at 5
kHz)
Other models:
MW: 531 – 1,602 kHz
(with the interval set at 9
kHz)
530 – 1,710 kHz
(with the interval set at 10
kHz)
SW: 5.95 – 17.90 MHz
(with the interval set at 5
kHz)
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
Specifications
Amplifier section
The following measured at AC 110, 220 V 50/60 Hz
DIN power output (rated) 60 + 60 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
80 + 80 watts
(6 ohms at 1 kHz,
10% THD)
The following measured at AC 120, 240 V 50/60 Hz
DIN power output (rated) 70 + 70 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
100 + 100 watts
(6 ohms at 1 kHz,
10% THD)
Inputs
MD/VIDEO (AUDIO) IN:voltage 450 mV/250 mV,
(phono jacks) impedance 47 kilohms
MIX MIC: sensitivity 1 mV,
(phone jack) impedance 10 kilohms
Outputs
MD/VIDEO (AUDIO) OUT:
(phono jacks) voltage 250 mV
impedance 1 kilohms
PHONES: accepts headphones of 8
(stereo mini jack) ohms or more
SPEAKER: accepts impedance of 6 to
16 ohms
SUPER WOOFER : voltage 1V, impedance
1 kilohm
VIDEO CD/CD player section
System Compact disc, digital
audio and video system
Laser Semiconductor laser
(λ=780nm)
Emission duration:
continuous
Laser output Max. 44.6
µ
W*
*This output is the value
measured at a distance of
200 mm from the
objective lens surface on
the Optical Pick-up Block
with 7 mm aperture.
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Wavelength 780 – 790 nm
Signal-to-noise ratio More than 90 dB
Dynamic range More than 90 dB
Video color system format
NTSC , PAL
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Wavelength 660 nm
Output Level –18 dBm
continued
