6-23
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R067 1-208-689-11 METAL CHIP 1.8K 0.5% 1/16W
R068 1-218-978-11 METAL CHIP 120K 0.5% 1/16W
R069 1-218-965-11 RES-CHIP 10K 5% 1/16W
R070 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R071 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R072 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R073 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R074 1-218-965-11 RES-CHIP 10K 5% 1/16W
R075 1-500-329-21 FERRITE 0uH (Note)
R076 1-218-990-11 SHORT 0
R077 1-500-329-21 FERRITE 0uH (Note)
R079 1-218-953-11 RES-CHIP 1K 5% 1/16W
R080 1-218-973-11 RES-CHIP 47K 5% 1/16W
R083 1-218-990-11 SHORT 0 (CD200)
R084 1-218-971-11 RES-CHIP 33K 5% 1/16W
R085 1-218-990-11 SHORT 0
R101 1-218-990-11 SHORT 0 (CD300)
R102 1-218-990-11 SHORT 0 (CD300)
R105 1-218-990-11 SHORT 0
R108 1-218-990-11 SHORT 0 (CD300)
R109 1-218-990-11 SHORT 0 (CD200)
R202 1-218-990-11 SHORT 0
R204 1-218-953-11 RES-CHIP 1K 5% 1/16W
R205 1-218-989-11 RES-CHIP 1M 5% 1/16W
R206 1-218-939-11 RES-CHIP 68 5% 1/16W
R251 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R252 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R253 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R254 1-218-990-11 SHORT 0
R256 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R257 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R259 1-218-973-11 RES-CHIP 47K 5% 1/16W
R260 1-218-949-11 RES-CHIP 470 5% 1/16W
R261 1-218-973-11 RES-CHIP 47K 5% 1/16W
R262 1-218-970-11 RES-CHIP 27K 5% 1/16W
R264 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R265 1-218-990-11 SHORT 0
R266 1-218-971-11 RES-CHIP 33K 5% 1/16W
R267 1-218-941-11 RES-CHIP 100 5% 1/16W
R268 1-218-953-11 RES-CHIP 1K 5% 1/16W
R270 1-218-990-11 SHORT 0
R271 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R272 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R273 1-218-941-11 RES-CHIP 100 5% 1/16W
R274 1-218-971-11 RES-CHIP 33K 5% 1/16W
R276 1-218-977-11 RES-CHIP 100K 5% 1/16W
R277 1-218-973-11 RES-CHIP 47K 5% 1/16W
R278 1-218-973-11 RES-CHIP 47K 5% 1/16W
R279 1-218-977-11 RES-CHIP 100K 5% 1/16W
R280 1-218-975-11 RES-CHIP 68K 5% 1/16W
R281 1-208-635-11 RES-CHIP 10 5% 1/16W
R302 1-218-946-11 RES-CHIP 270 5% 1/16W
R305 1-218-953-11 RES-CHIP 1K 5% 1/16W
R306 1-218-990-11 SHORT 0 (CD200)
R308 1-218-977-11 RES-CHIP 100K 5% 1/16W
R309 1-218-990-11 SHORT 0
R310 1-218-990-11 SHORT 0
R311 1-218-990-11 SHORT 0 (CD300)
R312 1-218-945-11 METAL CHIP 220 0.5% 1/16W
R313 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R314 1-218-958-11 METAL CHIP 2.7K 0.5% 1/16W
R315 1-218-973-11 RES-CHIP 47K 5% 1/16W
R316 1-218-939-11 METAL CHIP 68 0.5% 1/16W
R317 1-208-661-11 METAL CHIP 120 0.5% 1/16W
R318 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R319 1-218-958-11 METAL CHIP 2.7K 0.5% 1/16W
R320 1-218-973-11 RES-CHIP 47K 5% 1/16W
R321 1-218-952-11 RES-CHIP 820 5% 1/16W
R322 1-218-969-11 RES-CHIP 22K 5% 1/16W
R323 1-218-937-11 RES-CHIP 47 5% 1/16W
R324 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R325 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R326 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R327 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R328 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R329 1-218-947-11 RES-CHIP 330 5% 1/16W
R330 1-218-952-11 RES-CHIP 820 5% 1/16W
R331 1-218-947-11 RES-CHIP 330 5% 1/16W
R332 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R333 1-218-849-11 METAL CHIP 1.2K 0.5% 1/16W
R334 1-208-885-11 METAL CHIP 820 0.5% 1/16W
R335 1-218-941-11 METAL CHIP 100 0.5% 1/16W
R336 1-218-941-11 METAL CHIP 100 0.5% 1/16W
R337 1-218-990-11 SHORT 0 (CD300)
R338 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R341 1-216-864-11 METAL CHIP 0 5% 1/16W
R342 1-218-953-11 RES-CHIP 1K 5% 1/16W
R343 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R344 1-218-949-11 RES-CHIP 470 5% 1/16W
R401 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R402 1-218-949-11 RES-CHIP 470 5% 1/16W
R404 1-218-977-11 RES-CHIP 100K 5% 1/16W
R407 1-218-965-11 RES-CHIP 10K 5% 1/16W
R408 1-218-965-11 RES-CHIP 10K 5% 1/16W
R409 1-218-985-11 RES-CHIP 470K 5% 1/16W
R410 1-218-985-11 RES-CHIP 470K 5% 1/16W
R412 1-218-985-11 RES-CHIP 470K 5% 1/16W
R413 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R414 1-218-985-11 RES-CHIP 470K 5% 1/16W
R415 1-218-985-11 RES-CHIP 470K 5% 1/16W
R416 1-218-985-11 RES-CHIP 470K 5% 1/16W
R417 1-218-985-11 RES-CHIP 470K 5% 1/16W
R418 1-218-985-11 RES-CHIP 470K 5% 1/16W
R419 1-218-985-11 RES-CHIP 470K 5% 1/16W
R420 1-218-973-11 RES-CHIP 47K 5% 1/16W
R421 1-218-989-11 RES-CHIP 1M 5% 1/16W
R422 1-218-953-11 RES-CHIP 1K 5% 1/16W
R423 1-218-989-11 RES-CHIP 1M 5% 1/16W
R424 1-218-949-11 RES-CHIP 470 5% 1/16W
R425 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R426 1-218-983-11 RES-CHIP 330K 5% 1/16W
R427 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R428 1-218-965-11 RES-CHIP 10K 5% 1/16W
R429 1-218-977-11 RES-CHIP 100K 5% 1/16W
R430 1-218-943-11 RES-CHIP 150 5% 1/16W
R431 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R432 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R434 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R435 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R436 1-218-983-11 RES-CHIP 330K 5% 1/16W
SY-67
Note : Ferrites are mounted to the location where R075, R077
are printed.
