6-24E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R437 1-218-975-11 RES-CHIP 68K 5% 1/16W
R438 1-218-989-11 RES-CHIP 1M 5% 1/16W
R441 1-218-953-11 RES-CHIP 1K 5% 1/16W
R445 1-218-953-11 RES-CHIP 1K 5% 1/16W
R446 1-218-953-11 RES-CHIP 1K 5% 1/16W
R447 1-218-965-11 RES-CHIP 10K 5% 1/16W
R448 1-218-953-11 RES-CHIP 1K 5% 1/16W
R449 1-218-953-11 RES-CHIP 1K 5% 1/16W
R450 1-218-965-11 RES-CHIP 10K 5% 1/16W
R451 1-218-953-11 RES-CHIP 1K 5% 1/16W
R452 1-218-965-11 RES-CHIP 10K 5% 1/16W
R453 1-218-953-11 RES-CHIP 1K 5% 1/16W
R454 1-218-953-11 RES-CHIP 1K 5% 1/16W
R455 1-218-985-11 RES-CHIP 470K 5% 1/16W
R456 1-218-953-11 RES-CHIP 1K 5% 1/16W
R457 1-218-985-11 RES-CHIP 470K 5% 1/16W
R463 1-218-977-11 RES-CHIP 100K 5% 1/16W
R464 1-218-977-11 RES-CHIP 100K 5% 1/16W
R465 1-218-977-11 RES-CHIP 100K 5% 1/16W
R466 1-218-953-11 RES-CHIP 1K 5% 1/16W
R467 1-218-953-11 RES-CHIP 1K 5% 1/16W
R468 1-218-953-11 RES-CHIP 1K 5% 1/16W
R469 1-218-953-11 RES-CHIP 1K 5% 1/16W
R470 1-218-990-11 SHORT 0
R471 1-218-953-11 RES-CHIP 1K 5% 1/16W
R472 1-218-985-11 RES-CHIP 470K 5% 1/16W
R473 1-218-969-11 RES-CHIP 22K 5% 1/16W
R474 1-218-977-11 RES-CHIP 100K 5% 1/16W
R478 1-218-953-11 RES-CHIP 1K 5% 1/16W
R479 1-218-953-11 RES-CHIP 1K 5% 1/16W
R506 1-218-973-11 RES-CHIP 47K 5% 1/16W
R507 1-218-973-11 RES-CHIP 47K 5% 1/16W
R509 1-218-973-11 RES-CHIP 47K 5% 1/16W
R510 1-218-973-11 RES-CHIP 47K 5% 1/16W
R511 1-218-965-11 RES-CHIP 10K 5% 1/16W
R512 1-218-973-11 RES-CHIP 47K 5% 1/16W
R513 1-218-953-11 RES-CHIP 1K 5% 1/16W
R514 1-218-953-11 RES-CHIP 1K 5% 1/16W
R515 1-218-953-11 RES-CHIP 1K 5% 1/16W
R516 1-218-973-11 RES-CHIP 47K 5% 1/16W
R517 1-218-953-11 RES-CHIP 1K 5% 1/16W
R519 1-218-973-11 RES-CHIP 47K 5% 1/16W
R520 1-218-977-11 RES-CHIP 100K 5% 1/16W
R521 1-218-973-11 RES-CHIP 47K 5% 1/16W
R522 1-218-953-11 RES-CHIP 1K 5% 1/16W
R525 1-218-990-11 SHORT 0
R526 1-218-973-11 RES-CHIP 47K 5% 1/16W
R527 1-218-973-11 RES-CHIP 47K 5% 1/16W
R528 1-216-864-11 METAL CHIP 0 5% 1/16W
R531 1-218-973-11 RES-CHIP 47K 5% 1/16W
R532 1-216-295-91 SHORT 0
R533 1-218-973-11 RES-CHIP 47K 5% 1/16W
R534 1-218-973-11 RES-CHIP 47K 5% 1/16W
R535 1-218-973-11 RES-CHIP 47K 5% 1/16W
R536 1-218-973-11 RES-CHIP 47K 5% 1/16W
R537 1-216-864-11 METAL CHIP 0 5% 1/16W
R538 1-218-990-11 SHORT 0
R541 1-218-977-11 RES-CHIP 100K 5% 1/16W
R542 1-218-973-11 RES-CHIP 47K 5% 1/16W
R544 1-218-973-11 RES-CHIP 47K 5% 1/16W
R711 1-218-990-11 SHORT 0
R718 1-218-965-11 RES-CHIP 10K 5% 1/16W
R719 1-218-947-11 RES-CHIP 330 5% 1/16W
R720 1-218-967-11 RES-CHIP 15K 5% 1/16W
R721 1-218-953-11 RES-CHIP 1K 5% 1/16W
R723 1-218-990-11 SHORT 0
R724 1-218-953-11 RES-CHIP 1K 5% 1/16W
R901 1-218-965-11 RES-CHIP 10K 5% 1/16W
R902 1-216-864-11 METAL CHIP 0 5% 1/16W
* R903 1-500-282-11 FERRITE 0uH
* R906 1-500-282-11 FERRITE 0uH
R907 1-208-635-11 RES-CHIP 10 5% 1/16W
R908 1-218-941-11 RES-CHIP 100 5% 1/16W
R909 1-208-635-11 RES-CHIP 10 5% 1/16W
R910 1-216-864-11 METAL CHIP 0 5% 1/16W
R912 1-208-635-11 RES-CHIP 10 5% 1/16W
R913 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S401 1-771-331-61 SWITCH, PUSH (1 KEY)(FLASH OPEN/CLOSE)
< TRANSFORMER >
0 T001 1-429-565-21 TRANSFORMER, CONVERTER
< VIBRATOR >
X401 1-795-244-11 VIBRATOR, CERAMIC (10MHz)
X402 1-760-458-21 VIBRATOR, CRYSTAL (32.768KHz)
X901 1-795-171-21 OSCILLATOR, CRYSTAL (48MHz)
**************************************************************
SY-67
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
