– 8 –
2 boss
3 MD mechanism deck
(MT-MZR90-165)
2 boss
4 tension spring (arm)
5 set chassis ass
y
1 screw (1.4)
1 screw (1.4)
8 bearing
5 screw
4 rack spring
3 precision pan screw
(M1.4)
1 washer (0.8 - 2.5)
2 gear (SA)
5 screw
7 Pull off the lead screw.
6
B
A
9 Opening the over write head
toward the direction A, remove th
e
OP Service assy toward
the direction B.
Note: Do not open the entire assy
forcibly, when opening
the over write head.
over write head section
“CHASSIS ASSY, SET”, MD MECHANISM DECK (MT-MZR90-165)
SERVICE ASSY, OP
