40
BLACK LEVEL
To set the black level.
GAMMA
To select a gamma curve.
BLACK GAMMA
To correct gamma in low intensity area.
KNEE
To set knee point and slope for video signal compression to prevent over-exposure by limiting
signals in high intensity areas of the subject to the dynamic range of your camcorder.
Item Description and settings
Sets the black level.
-15 to +15
Item Description and settings
[STANDARD] Standard gamma curve
[CINEMATONE1] Gamma curve 1 for producing tone of film camera images
[CINEMATONE2] Gamma curve 2 for producing tone of film camera images
[ITU709] Gamma curve that corresponds to ITU-709. Gain in low intensity area:
4.5
Item Description and settings
[RANGE] Selects a correcting range.
HIGH / MIDDLE / LOW
[LEVEL] Sets the correcting level.
-7 (maximum black compression) to +7 (maximum black stretch)
Item Description and settings
[MODE] Selects a mode either automatic or manual.
[AUTO] : to set the knee point and slope automatically.
[MANUAL] : to set the knee point and slope manually.
[AUTO SET] Sets the maximum point and sensitivity in the automatic mode.
[MAX POINT] : Sets the maximum point.
90% to 100%
[SENSITIVITY] : Sets the sensitivity.
HIGH / MIDDLE / LOW
[MANUAL SET] Sets the knee point and slope manually.
[POINT] : Sets the knee point.
75% to 105%
[SLOPE] : Sets the knee slope.
-5 (gentle) to +5 (steep)
Useful functions (Continued)
