20
NW-E99
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1095-905-A DISPLAY BOARD, COMPLETE
************************
1-805-081-12 ELEMENT, EL
1-805-082-11 DISPLAY PANEL, LIQUID CRYSTAL
2-024-570-01 SPACER (JACK)
2-024-571-01 SPACER (BUTTON)
3-247-203-02 HOLDER, LCD
3-252-983-01 CUSHION (EL)
< CAPACITOR >
C522 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C700 1-756-305-11 BATTERY, PAS SECONDARY
C702 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C801 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C802 1-100-437-91 CERAMIC CHIP 4700PF 5% 10V
C850 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C851 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C852 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C853 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C860 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C861 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C862 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C863 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C864 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C865 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C866 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C867 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN402 1-818-409-21 CONNECTOR, BOARD TO BOARD 24P
CN850 1-818-411-21 CONNECTOR, FFC/FPC LIF 20P
< DIODE >
D702 6-500-653-01 DIODE SML-512DWT86 (ACCESS)
D703 8-719-069-29 DIODE RB520S-30TE61
D801 8-719-052-12 DIODE 1SS403 (TPH3)
< IC >
IC801 6-703-296-01 IC SM8145AB-G-EL
< COIL >
L801 1-414-406-41 INDUCTOR 220uH
< TRANSISTOR >
Q701 8-729-056-42 TRANSISTOR 2SC5658T2L
< RESISTOR >
R700 1-218-973-11 RES-CHIP 47K 5% 1/16W
R701 1-218-969-11 RES-CHIP 22K 5% 1/16W
R704 1-218-969-11 RES-CHIP 22K 5% 1/16W
R706 1-218-977-11 RES-CHIP 100K 5% 1/16W
R708 1-218-973-11 RES-CHIP 47K 5% 1/16W
R710 1-218-953-11 RES-CHIP 1K 5% 1/16W
R713 1-218-941-81 RES-CHIP 100 5% 1/16W
R801 1-218-977-11 RES-CHIP 100K 5% 1/16W
R802 1-218-971-11 RES-CHIP 33K 5% 1/16W
R803 1-218-973-11 RES-CHIP 47K 5% 1/16W
R804 1-218-971-11 RES-CHIP 33K 5% 1/16W
R805 1-218-979-11 RES-CHIP 150K 5% 1/16W
R850 1-218-977-11 RES-CHIP 100K 5% 1/16W
R851 1-218-977-11 RES-CHIP 100K 5% 1/16W
R852 1-218-979-11 RES-CHIP 150K 5% 1/16W
R860 1-218-990-11 SHORT CHIP 0
R861 1-218-990-11 SHORT CHIP 0
R862 1-218-990-11 SHORT CHIP 0
R863 1-218-990-11 SHORT CHIP 0
R864 1-218-990-11 SHORT CHIP 0
R865 1-218-990-11 SHORT CHIP 0
R866 1-218-990-11 SHORT CHIP 0
< SWITCH >
S701 1-786-740-21 SWITCH, PUSH (1 KEY) (./– +/>)
S704 1-786-453-21 SWITCH, TACTILE (MENU)
S705 1-786-453-21 SWITCH, TACTILE (• REPEAT SOUND)
S708 1-786-453-21 SWITCH, TACTILE (GROUP)
************************************************************
X-2102-785-1 MAIN BOARD, COMPLETE
*********************
2-024-569-01 SPACER (USB)
3-266-603-01 SPRING (BATTERY TERMINAL)
3-266-685-01 TERMINAL (-), BATTERY
< CAPACITOR >
C100 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C101 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C102 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C103 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C104 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C200 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C201 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C202 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C203 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
When indicating parts by reference number,
please include the board name.
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
CND : Canadian model
HK : Hong Kong model
JE : Tourist model
KR : Korea model
MAINDISPLAY
Ver. 1.5
