Sony NW-E99 - 3 Disassembly; Case, Chassis (Front) Assy

6
NW-E99
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
Note: Disassemble the unit in the order as shown below.
3-1. CASE, CHASSIS (FRONT) ASSY
SET
3-1. CASE,CHASSIS (FRONT) ASSY
(Page 6)
3-2. DISPLAY BOARD ASSY
(Page 7)
3-3. MAIN BOARD ASSY
(Page 7)
1 case
3 chassis (front)
4 three button (cup)
5 window (led)
2 three claws
