– 51 –
151
152
153
154
155
156
159
160
157
158
161
S301
S302
M301
#7
#7
#8
#6
#6
162
6-4. CASSETTE MECHANISM SECTION-1
(MF-107)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
151 3-362-979-01 FW ASSY
152 3-369-961-01 WASHER
153 3-362-989-01 BELT
154 3-362-970-01 SPRING
155 3-362-971-01 SPRING
* 156 3-362-988-01 HOLDER, MOTOR
157 3-362-980-01 WASHER
158 3-379-843-01 SPRING
159 3-026-316-01 SPRING, REC
160 3-362-967-01 SPRING, CASSETTE
* 161 1-670-428-11 REC SW BOARD
162 3-014-779-01 C SCREW 2X3
M301 X-3365-538-1 MOTOR ASSY (CAPSTAN/REEL)
S301 1-571-556-11 SWITCH, LEAF (MD POWER)
S302 1-571-556-11 SWITCH, LEAF (MD PLAY)
To Next Page
