Sony PMC-107 - Cassette Mechanism Section-2

– 52 –
201
202
203
204
205
206
207
208
211
212
210
209
6-5. CASSETTE MECHANISM SECTION-2
(MF-107)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
201 3-366-352-01 SCREW
202 3-369-961-01 WASHER
203 3-369-962-01 SPRING, COMPRESSION
204 X-3363-315-1 GEAR, CAM
205 3-362-973-01 AS (BASE)
206 3-362-976-01 LEVER, CONTROL
207 3-362-975-01 LEVER, SENSOR
208 3-362-977-01 SPRING
209 3-362-978-01 SPRING, PLATE
210 3-379-844-01 PLATE, STOP, FR
211 3-387-697-01 SENSOR
212 3-362-969-01 IDLER ASSY, PF
